Earth-leakage VigiPacT add-on protection module, ComPacT NSX 100/160, 200VAC to 440VAC, 30mA to 30A, 3 poles - LV429488
SKU : LV429488
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Earth-leakage VigiPacT add-on protection module, ComPacT NSX 100/160, 200VAC to 440VAC, 30mA to 30A, 3 poles - LV429488
DESCRIPTION
- Main
- range of product : ComPacT NSX100...250 new generation
ComPact NSX100...250 - device short name : VigiPacT
- product or component type : Vigi add-on
- device application : Wiring
- range compatibility : ComPacT NSX100 new generation circuit breaker
ComPacT NSX160 new generation circuit breaker
ComPact NSX100 circuit breaker
ComPact NSX160 circuit breaker - poles description : 3P
- [In] rated current : 100 A
160 A - earth-leakage protection class : Class A
Class AC - residual earth-leakage sensitity adjustment type : Adjustable
- earth-leakage sensitivity : 0.03 A for class A
0.1 A for class A
0.3 A for class A
0.5 A for class A
1 A for class A
3 A for class A
10 A for class AC
30 A for class AC - residual earth-leakage time delay adjustment type : Adjustable
- [Δt] residual earth-leakage time delay adjustment : 0 ms
60 ms
150 ms
300 ms
500 ms
800 ms
1.2 s
4 s
- range of product : ComPacT NSX100...250 new generation
- Complementary
- network type : AC
- network frequency : 50/60 Hz
- [Ue] rated operational voltage : 200...440 V AC 50/60 Hz conforming to IEC 60947-2
- earth-leakage protection : With
- maximum breaking time : 800 ms
- overvoltage category : IV
- Environment
- electrical shock protection class : Class II
- standards : IEC 60947-2
- Offer Sustainability
- Sustainable offer status : Green Premium product
- REACh Regulation : Reference contains Substances of Very High Concern above the threshold
- EU RoHS Directive : Compliant
- Mercury free : Yes
- RoHS exemption information : Yes
- China RoHS Regulation : Product out of China RoHS scope. Substance declaration for your information
- Environmental Disclosure : ENVPEP2102011_V1
- Circularity Profile : ENVEOLI2102011_V1
- WEEE : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
| Code EAN: | 3606481298546 |
|---|
