energy sensor PowerTag Flex 63A 3P top and bottom position - A9MEM1573
DESCRIPTION
| Range: | PowerLogic |
|---|---|
| Product name: | PowerTag A9 F63 |
| Product or component type: | Energy sensor |
| Poles description: | 3P |
| Max current: | 63 A |
| [Ib] basic current: | 10 A |
| Starting current: | 40 mA |
| Saturation current: | 130 A |
| Product specific application: | Cost allocationLoad monitoringOverload alarmCircuit monitoringEnergy management |
| Concentrator compatibility: | Acti9 PowerTag LinkActi9 PowerTag Link HDHarmony HubEcoStruxure Panel Server UniversalEcoStruxure Panel Server AdvancedPrismaSet Active |
| Market segment: | Buildings: breaker voltage monitoringBuildings: cost allocationBuildings: overload alarm |
| Range compatibility: | TeSys TeSys D LC1D contactor de In Acti 9 circuit breaker de In TeSys TeSys GV2 circuit breaker de TeSys TeSys GV3 circuit breaker de In Acti 9 Acti9 DT40 VigiActi 9 Acti9 iDT40Acti 9 Acti9 iC40Acti 9 Acti9 C40Acti 9 Acti9 iC60Multi9 Multi9 C60Acti 9 Acti9 iDPN VigiActi 9 Acti9 C120In Acti 9 Acti9 NG125In TeSys TeSys UTeSys TeSys K |
| Type of measurement: | VoltageActive energyActive powerCurrentPower factor |
| Accuracy class: | Class 1 current conforming to IEC 61557-12Class 0.5 voltage conforming to IEC 61557-12Class 1 active power conforming to IEC 61557-12Class 1 active energy conforming to IEC 61557-12Class 1 power factor conforming to IEC 61557-12 |
| Mounting location: | Top or bottom |
| Mounting support: | On circuit breaker |
| Product destination: | Switchboard |
| Event management: | Voltage loss with measured current at voltage loss |
| Transmission support medium: | Radio frequency 2.4...2.4835 GHz conforming to IEEE 802.15.4 |
| Maximum emission power: | 10 mW |
| Form factor: | Flex |
|---|---|
| Mounting mode: | By screws (terminals) |
| Electrical connection: | Wires with cable end |
| Cable cross section: | 1 rigid cable 1.5...16 mm²2 stranded cable 1.5...2.5 mm²2 rigid cable 1.5...2.5 mm²1 stranded cable 1.5...16 mm² |
| Cable length: | 0.25 m |
| [Ue] rated operational voltage: | 380...415 V AC, +/- 20 %, between phases |
| Network frequency: | 50 Hz60 Hz |
| Maximum power consumption in VA: | 2 VA |
| Standards: | IEC 61557-12IEC 61010-1IEC 61010-2-030IEC 61326-1ETSI EN 300 328ETSI EN 301 487-1 |
| Height: | Sensor element: 19.5 mm |
| Width: | Sensor element: 54 mm |
| Depth: | Sensor element: 43 mm |
| Net weight: | 38 g |
| Colour: | White (RAL 9003) |
| Compatibility code: | PowerTag A9 P63 |
| Quality labels: | CE |
|---|---|
| Directives: | 2014/53/EU - radio equipment directive |
| Operating altitude: | 0...2000 m |
| Ambient air temperature for operation: | -25...60 °C |
| Ambient air temperature for storage: | -40...85 °C |
| Overvoltage category: | III conforming to IEC 61010-1 |
| Measurement category: | Category III conforming to IEC 61010-2-030 |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| IK degree of protection: | IK05 |
| Pollution degree: | 3 |
| Relative humidity: | 0...95 % at 45 °C conforming to IEC 60721-3-3 |
| Vibration resistance: | 3M4 conforming to IEC 60721-3-3 |
| Electromagnetic compatibility: | Industrial electromagnetic environment conforming to IEC 61326-1Radiated EMC conforming to ETSI EN 301 489-17Electromagnetic emission conforming to IEC 62311 |
| Environmental characteristic: | Dustproof class 3S3 conforming to IEC 60721-3-3Salt mist class 3C2 conforming to IEC 60721-3-3Indoor use |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606489940843 |
|---|
