energy sensor, PowerTag Rope 1000A 3P/3P+N top and bottom position - A9MEM1592
SKU : A9MEM1592
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
energy sensor, PowerTag Rope 1000A 3P/3P+N top and bottom position - A9MEM1592
DESCRIPTION
| Range: | PowerLogic |
|---|---|
| Product name: | PowerTag R1000 |
| Product or component type: | Energy sensor |
| Poles description: | 3P3P + N |
| Max current: | 1000 A |
| [Ib] basic current: | 150 A |
| Starting current: | 600 mA |
| Saturation current: | 2000 A |
| Product specific application: | Energy managementOverload alarmPower factorLoad monitoringCircuit monitoring |
| Concentrator compatibility: | Acti9 PowerTag Link CActi9 PowerTag LinkActi9 PowerTag Link HDHarmony HubEcoStruxure Panel Server UniversalEcoStruxure Panel Server AdvancedPrismaSet Active |
| Range compatibility: | Masterpact MasterPact MTZ switch disconnector de Masterpact MasterPact NWMasterpact MasterPact NTComPact ComPact NS |
| Type of measurement: | Active and reactive energyApparent energyActive and reactive powerApparent powerCurrentVoltagePower factorInternal temperatureFrequency |
| Accuracy class: | Class 1 active energy conforming to IEC 61557-12Class 2 reactive energy conforming to IEC 61557-12Class 2 apparent energy conforming to IEC 61557-12Class 1 active power conforming to IEC 61557-12Class 2 reactive power conforming to IEC 61557-12Class 2 apparent power conforming to IEC 61557-12Class 1 current conforming to IEC 61557-12Class 0.5 voltage conforming to IEC 61557-12Class 1 power factor conforming to IEC 61557-12Class 0.5 frequency conforming to IEC 61557-12 |
| Metering type: | Active energy E -a- IN/OUT 0...281 x 10exp(9) kWh at total per phaseActive energy E -a- IN/OUT 0...281 x 10exp(9) kWh at partial per phaseActive energy E -a- IN/OUT 0...281 x 10exp(9) kWh at 3-phase totalActive energy E -a- IN/OUT 0...281 x 10exp(9) kWh at 3-phase partialReactive energy E -rA- IN/OUT 0...281 x 10exp(9) kVARh at total per phaseReactive energy E -rA- IN/OUT 0...281 x 10exp(9) kVARh at partial per phaseReactive energy E -rA- IN/OUT 0...281 x 10exp(9) kVARh at 3-phase totalReactive energy E -rA- IN/OUT 0...281 x 10exp(9) kVARh at 3-phase partialApparent energy E -apA- 0...281 x 10exp(9) kVAh at total per phaseApparent energy E -apA- 0...281 x 10exp(9) kVAh at partial per phaseApparent energy E -apA- 0...281 x 10exp(9) kVAh at 3-phase totalApparent energy E -apA- 0...281 x 10exp(9) kVAh at 3-phase partialActive power P, P1, P2, P3Reactive power Q, Q1, Q2, Q3Apparent power S, S1, S2, S3Current I1, I2, I3Calculated neutral currentVoltage U12, U23, U31Voltage V1N, V2N, V3NFrequency 45...65 HzPower factor at per phasePower factor at total |
| Mounting location: | Top or bottom |
| Mounting support: | BusbarCables |
| Product destination: | Switchboard |
| Event management: | Voltage loss with measured current at voltage loss |
| Transmission support medium: | Radio frequency 2.4...2.4835 GHz conforming to IEEE 802.15.4 |
| Emission power: | 10 mW |
| Form factor: | Rope |
|---|---|
| Mounting mode: | Clip-on (DIN rail) |
| Electrical connection: | Removable spring terminal block |
| Cable cross section: | 1 rigid cable 0.2...1.5 mm² without cable end1 stranded cable 0.2...2.5 mm² without cable end1 stranded cable 0.25...1.5 mm² with cable end |
| Wire stripping length: | 11 mm |
| Cable length: | 1 m for sensor |
| Diameter: | Closed: 100 mm |
| [Ue] rated operational voltage: | 100...277 V AC, +/- 20 %, phase to neutral173...480 V AC, +/- 20 %, phase to phase |
| Network frequency: | 50 Hz60 Hz |
| Power consumption in VA: | 3 VA |
| Standards: | IEC 61557-12IEC 61010-1ETSI EN 301 487-1IEC 61010-2-030IEC 61326-1ETSI EN 300 328 |
| 9 mm pitches: | 2 |
| Height: | Base unit: 105 mm |
| Width: | Base unit: 18 mm |
| Depth: | Base unit: 67.5 mm |
| Colour: | White (RAL 9003) |
| Maximum conductor temperature: | 105 °C |
|---|---|
| Quality labels: | CE |
| Directives: | 2014/53/EU - radio equipment directive |
| Operating altitude: | 0...2000 m |
| Ambient air temperature for operation: | -25...70 °C |
| Ambient air temperature for storage: | -40...85 °C |
| Overvoltage category: | IV conforming to IEC 61010-1 |
| Measurement category: | Category IV conforming to IEC 61010-2-030 |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| IK degree of protection: | IK05 |
| Pollution degree: | 3 |
| Relative humidity: | 0...95 % at 55 °C conforming to IEC 60721-3-3 |
| Vibration resistance: | 3M4 conforming to IEC 60721-3-3 |
| Electromagnetic compatibility: | Industrial electromagnetic environment conforming to IEC 61326-1Radiated EMC conforming to ETSI EN 301 489-17Electromagnetic emission conforming to IEC 62311 |
| Environmental characteristic: | Indoor use |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606481595300 |
|---|
