Floor standing enclosure polyester vers.PLA completely sealed 1500x1250x420 IP65 - NSYPLA15124G
DESCRIPTION
| Range: | Thalassa |
|---|---|
| Product name: | Thalassa PLA |
| Device application: | Multi-purpose |
| Product or component type: | Suitable enclosure |
| Device short name: | PLA |
| Enclosure nominal height: | 1500 mm |
| Enclosure nominal width: | 1250 mm |
| Enclosure nominal depth: | 420 mm |
| Enclosure mounting: | Floor-standing |
| Device composition: | 1 top part1 bottom part2 side part2 door2 rear panel |
| Body type: | Sealed top and bottom part assembled with side parts |
|---|---|
| Door type: | Plain front |
| Number of doors: | 2 door(s) |
| Door opening side: | Right and left (120 °) |
| Lock type: | 4 points lock, 5 mm double-bar |
| Accessibility for operation: | RearFront |
| Removable parts: | Door by hingesRear panel by fixing element |
| Material: | Polyester reinforced with fibreglass |
| Colour: | Grey (RAL 7035) |
| Standards: | IEC 62208UL 508 A |
| NEMA degree of protection: | NEMA 1NEMA 2NEMA 13NEMA 12 |
| Product certifications: | DNV MarineVeritasUL/cUL listed |
| Electrical insulation class: | Class II |
| IP degree of protection: | IP65 conforming to IEC 60529 (completely sealed) |
|---|---|
| IK degree of protection: | IK10 conforming to IEC 62262 (plain door) |
| Fire resistance: | 960 °C conforming to IEC 62208 |
| Ambient air temperature for storage: | -35...90 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3606480774737 |
|---|
