Head for pilot light, Harmony XB4, metal, yellow, 22mm, universal LED, plain lens, for insertion of image - ZB4BV083E
SKU : ZB4BV083E
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Head for pilot light, Harmony XB4, metal, yellow, 22mm, universal LED, plain lens, for insertion of image - ZB4BV083E
DESCRIPTION
| Range of product: | Harmony XB4 |
|---|---|
| Product or component type: | Head for pilot light |
| Product compatibility: | Universal LED |
| Device short name: | ZB4 |
| Bezel material: | Chromium plated metal |
| Mounting diameter: | 22 mm |
| Sale per indivisible quantity: | 1 |
| Shape of signaling unit head: | Round |
| Cap/operator or lens colour: | Yellow |
| Operator additional information: | With plain lens, for insertion of legend |
| CAD overall width: | 29 mm |
|---|---|
| CAD overall height: | 29 mm |
| CAD overall depth: | 30 mm |
| Net weight: | 0.026 kg |
| Resistance to high pressure washer: | 7000000 Pa at 55 °C, distance |
| Electrical composition code: | P1 in front mounting with integral LEDP2 in front mounting with integral LED and transformer |
| Main group: | Pilot light |
| Group of product: | Legend insert. Integral LED |
| Cap/operator or lens colour: | Yellow |
| Device presentation: | Basic element |
| Compatibility code: | ZB4 |
| Protective treatment: | TH |
|---|---|
| Ambient air temperature for storage: | -40...70 °C |
| Ambient air temperature for operation: | -40...70 °C |
| Overvoltage category: | Class I conforming to IEC 60536 |
| IP degree of protection: | IP66 conforming to IEC 60529IP67IP69IP69K |
| NEMA degree of protection: | NEMA 13NEMA 4X |
| IK degree of protection: | IK06 conforming to IEC 50102 |
| Standards: | IEC 60947-5-5IEC 60947-1CSA C22.2 No 14IEC 60947-5-1JIS C8201-5-1UL 508IEC 60947-5-4JIS C8201-1 |
| Vibration resistance: | 5 gn (f= 2...500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance: | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-2750 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606481202260 |
|---|
