High power contactor, TeSys Giga, 4 pole (4NO), AC-1 <=440V 550A, standard version, 100…250V wide band AC/DC coil - LC1G4004KUEN
SKU : LC1G4004KUEN
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
High power contactor, TeSys Giga, 4 pole (4NO), AC-1 <=440V 550A, standard version, 100…250V wide band AC/DC coil - LC1G4004KUEN
DESCRIPTION
| Range: | TeSys |
|---|---|
| Range of product: | TeSys Giga |
| Product or component type: | Contactor |
| Device short name: | LC1G |
| Contactor application: | Power switching |
| Utilisation category: | AC-1AC-5aAC-5bAC-6aAC-6bDC-1DC-3DC-5 |
| Poles description: | 4P |
| [Ue] rated operational voltage: | |
| [Ie] rated operational current: | 550 A (at |
| [Uc] control circuit voltage: | 100...250 V AC 50/60 Hz100...250 V DC |
| Control circuit voltage limits: | Operational: 0.8 Uc Min...1.1 Uc Max (at Drop-out: 0.1 Uc Max...0.45 Uc Min (at |
| Number of modules per PLC per PC: | 0 |
| [Uimp] rated impulse withstand voltage: | 8 kV |
|---|---|
| Overvoltage category: | III |
| [Ith] conventional free air thermal current: | 550 A (at 40 °C) |
| Rated breaking capacity: | 3480 A at 440 V |
| [Icw] rated short-time withstand current: | 3.6 kA - 10 s2.4 kA - 30 s1.7 kA - 1 min1.2 kA - 3 min1.0 kA - 10 min |
| Associated fuse rating: | 500 A aM at 315 A aM at 630 A gG at |
| Average impedance: | 0.0001 Ohm |
| [Ui] rated insulation voltage: | 1000 V |
| Power dissipation per pole: | 30 W AC-1 - Ith 550 A |
| Compatibility code: | LC1G |
| Pole contact composition: | 4 NO |
| Auxiliary contact composition: | 1 NO + 1 NC |
| Irms rated making capacity: | 5090 A at 440 V |
| Control circuit voltage limits: | Operational: 0.8...1.1 Uc AC/DC (at 60 °C)Drop-out: 0.1...0.45 Uc AC/DC (at 60 °C) |
| Coil technology: | Built-in bidirectional peak limiting |
| Electrical durability: | 300 cycles AC-1 at Ue 400 V |
| Mechanical durability: | 8 Mcycles |
| Inrush power in VA: | 750 VA |
| Inrush power in W: | 660 W |
| Hold-in power consumption in VA: | 15.5 VA |
| Hold-in power consumption in W: | 9.3 W |
| Operating time: | 40...70 ms closing15...50 ms opening |
| Maximum operating rate: | 300 cyc/h AC-1 |
| Connections - terminals: | Power circuit: bar 2 - busbar cross section: 32 x 10 mmPower circuit: lugs-ring terminals 1 185 mm²Control circuit: push-in 1 0.2...2.5 mm² - cable stiffness: solid stranded without cable endControl circuit: push-in 1 0.25...2.5 mm² - cable stiffness: flexible with cable endControl circuit: push-in 2 0.5...1.0 mm² with cable endControl circuit: push-in 0.75...2.5 mm² - cable stiffness: solid stranded without cable endControl circuit: push-in 0.75...2.5 mm² - cable stiffness: flexible with cable end |
| Connection pitch: | 45 mm |
| Mounting support: | Plate |
| Standards: | EN/IEC 60947-4-1EN/IEC 60947-5-1UL 60947-4-1CSA C22.2 No 60947-4-1JIS C8201-4-1JIS C8201-5-1 |
| Product certifications: | CB SchemeCCCcULusEACCEUKCAEU-RO-MR by DNV-GL |
| Tightening torque: | 35 N.m |
| Height: | 225 mm |
| Width: | 185 mm |
| Depth: | 226 mm |
| Net weight: | 8.2 kg |
| IP degree of protection: | IP2X front face with shrouds conforming to IEC 60529IP2X front face with shrouds conforming to VDE 0106 |
|---|---|
| Ambient air temperature for operation: | -25...60 °C |
| Ambient air temperature for storage: | -60...80 °C |
| Mechanical robustness: | Vibrations 5...300 Hz 2 gn contactor openVibrations 5...300 Hz 4 gn contactor closedShocks 10 gn 11 ms contactor openShocks 15 gn 11 ms contactor closed |
| Colour: | Dark grey |
| Protective treatment: | TH |
| Permissible ambient air temperature around the device: | -40...70 °C at Uc |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606481922182 |
|---|
