iQuick PRD8r modular surge arrester - 3 poles + N - 350V - with remote transfer - A9L16300
DESCRIPTION
| Range of product: | IQuick PRD |
|---|---|
| Range: | Acti 9 |
| Product name: | Acti 9 iQuick PRD |
| Product or component type: | Surge arrester with pluggable cartridge |
| Device short name: | IQuick PRD8r |
| Device application: | Distribution |
| Poles description: | 3P + N |
| Remote signalling: | With |
| Signal contacts composition: | 1 SD (1 C/O) |
| Surge arrester type: | Electrical distribution network |
| Earthing system: | TTTN-S |
| [Uoc] open circuit voltage: | 10 kV type 3 common mode L/PE10 kV type 3 common mode N/PE10 kV type 3 differential mode L/N |
| Surge arrester class type: | Type 2 + 3 |
|---|---|
| Surge arrester technology: | MOV + GDT |
| [Ue] rated operational voltage: | 230/400 V AC (+/- 10 %) at 50/60 Hz |
| Nominal discharge current: | Common mode: 2 kA (L/PE)Common mode: 2 kA (N/PE)Differential mode: 2 kA (L/N) |
| Maximum discharge current: | Common mode: 8 kA L/PECommon mode: 8 kA N/PEDifferential mode: 8 kA L/N |
| [Uc] maximum continuous operating voltage: | Common mode: 264 V N/PECommon mode: 350 V L/PEDifferential mode: 350 V L/N |
| Maximum [Up] voltage protection level: | Common mode Common mode Differential mode Common mode Differential mode Common mode |
| Disconnector device type: | Integrated circuit breaker - Icu 25 kA |
| Short-circuit withstand: | 25 kA |
| Signalling circuit voltage: | 2 A/250 V AC 50/60 Hz |
| Mounting mode: | Clip-on |
| Mounting support: | DIN rail |
| 9 mm pitches: | 14.6 |
| Height: | 94 mm |
| Width: | 131.5 mm |
| Depth: | 75.9 mm |
| Product weight: | 0.84 kg |
| Colour: | White (RAL 9003) |
| Response time: | |
| Connections - terminals: | Tunnel type terminal (downside) 2.5...25 mm²Tunnel type terminal (upside) 2.5...25 mm² |
| Tightening torque: | 2.5 N.m |
| Compatibility code: | IQuick PRD8r |
| Standards: | EN 61643-11:2012IEC 61643-11:2011 |
|---|---|
| Product certifications: | CE |
| Quality labels: | KEMA-KEURNF |
| IP degree of protection: | IP40 on front face: conforming to IEC 60529IP20 built-in: conforming to IEC 60529 |
| IK degree of protection: | IK05 conforming to IEC 62262 |
| Relative humidity: | 5...90 % |
| Operating altitude: | 2000 m |
| Ambient air temperature for operation: | -25...60 °C |
| Ambient air temperature for storage: | -40...70 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3606480387128 |
|---|
