Light block for head Ø22, white, integral LED, 110...120 V AC - ZBVG1
SKU : ZBVG1
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Light block for head Ø22, white, integral LED, 110...120 V AC - ZBVG1
DESCRIPTION
| Range of product: | Harmony XB4Harmony XB5 |
|---|---|
| Product or component type: | Light block |
| Device short name: | ZBV |
| Sale per indivisible quantity: | 1 |
| Connections - terminals: | Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN 60947-1Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to EN 60947-1 |
| Signalling type: | Steady |
| Light source: | Protected LED |
| Bulb base: | Integral LED |
| Light block supply: | Direct |
| Light source colour: | White |
| [Us] rated supply voltage: | 110...120 V AC at 50/60 Hz |
| Product weight: | 0.017 kg |
|---|---|
| Tightening torque: | 0.8...1.2 N.m conforming to EN 60947-1 |
| Shape of screw head: | Cross compatible with Philips no 1 screwdriverCross compatible with pozidriv No 1 screwdriverSlotted compatible with flat Ø 4 mm screwdriverSlotted compatible with flat Ø 5.5 mm screwdriver |
| Current consumption: | 14 mA |
| Service life: | 100000 h at rated voltage and 25 °C |
| Surge withstand: | 1 kV conforming to IEC 61000-4-5 |
| Mounting of block: | Front mounting |
| Electrical composition code: | M1M2M3M4M5M6M10MF1P1P2PF1 |
| Device presentation: | Basic element |
| Compatibility code: | ZBV |
| Protective treatment: | TH |
|---|---|
| Ambient air temperature for storage: | -40...70 °C |
| Ambient air temperature for operation: | -40...70 °C |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| Standards: | EN/IEC 60947-5-5UL 508JIS C8201-5-1EN/IEC 60947-5-4CSA C22.2 No 14EN/IEC 60947-5-1EN/IEC 60947-1JIS C8201-1 |
| Product certifications: | UL listedCSA |
| Resistance to fast transients: | 2 kV conforming to IEC 61000-4-4 |
| Resistance to electromagnetic fields: | 10 V/m conforming to IEC 61000-4-3 |
| Resistance to electrostatic discharge: | 6 kV on contact (on metal parts) conforming to IEC 61000-4-28 kV in free air (in insulating parts) conforming to IEC 61000-4-2 |
| Electromagnetic emission: | Class B conforming to IEC 55011 |
| [Us] rated supply voltage: | 110...120 V |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110089660 |
|---|
