LS Clario iC40 circuit breaker - 3P+N - 16A - curve C - 4500A/6kA A9P52716
DESCRIPTION
- Principales
Range: Acti9
Product Name: Acti9 iC40
Type of product or equipment: Miniature circuit breaker
Device name: IC40
Application: Distribution
Description of the poles: 3P + N
Number of poles protected: 3
Neutral pole position: Left
In rated operational current: 16 A
Grid Type: AC
Trigger type: Thermal-magnetic
Trigger curve: C
Breaking capacity: 4500 A Icn at 400 V AC 50/60 Hz conforming to EN/IEC 60898-1
6 kA Icu at 400 V AC 50/60 Hz conforming to EN/IEC 60947-2: Suitability for isolation
Yes conforming to EN/IEC 60947-2: Quality labels
IMQ
Mains frequency: 50/60 Hz
[Ue] rated operational voltage: 400 V AC 50/60 Hz
Magnetic tripping limit : 5,,,10 x In conforming to EN/IEC 60898-1
8 x In +/- 20 % conforming to EN/IEC 60947-2 : [Ics] service breaking capacity
4500 A 100 % Icn at 400 V AC 50/60 Hz conforming to EN/IEC 60898-1 : 4.5 kA 75 % Icu at 400 V AC 50/60 Hz conforming to EN/IEC 60947-2
Limitation class : 3 conforming to EN/IEC 60898-1
[Ui] insulation voltage : 440 V AC 50/60 Hz conforming to EN/IEC 60947-2
[Uimp] rated impulse withstand voltage : 4 kV conforming to EN/IEC 60947-2
Fully apparent cut: Yes
Type of control: By toggle
Voltage indication: ON/OFF indication
Trip indication: Installation mode
Snap-on: Mounting bracket
DIN rail: 9 mm pitch
6: Height
85mm: Width
54mm: Depth
74mm: Product weight
345g: Color
White: Mechanical Endurance
20000 cycles: Electrical life
20000 cycles: Optional interlocks
Padlocking device: Connection method
Tunnel type terminal top or bottom1...10 mm² flexible : Tunnel type terminal top or bottom1...16 mm² rigid
Wire stripping length: 14mm for top or bottom connection
tightening torque: 2 N.m top or bottom
Differential protection: Separate block
-
Environment
Standards: EN/IEC 60898-1
EN/IEC 60947-2: Product Certifications
EC: BV
RINA: DNV
IP degree of protection: IP20 conforming to IEC 60529
IP40 (modular enclosure) conforming to IEC 60529: Pollution degree
3 conforming to EN/IEC 60947-2: Relative humidity
95% at 55°C: Operating altitude
2000 m: Operating temperature
-25…70°C: Ambient storage temperature
-40…85 °C
| Code EAN: | 3606481325914 |
|---|
