Modular surge arrester, Acti9 iPRD1 12.5r, 1 P + N, 350 V, with remote transfert - A9L16282
SKU : A9L16282
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Modular surge arrester, Acti9 iPRD1 12.5r, 1 P + N, 350 V, with remote transfert - A9L16282
DESCRIPTION
| Range: | Acti9 |
|---|---|
| Product name: | Acti9 iPRD1 |
| Product or component type: | Surge arrester |
| Device short name: | iPRD1 12.5 |
| Device application: | Distribution |
| Standards: | EN 61643-11:2012IEC 61643-11:2011 |
| Quality labels: | CEEACVDE |
| Poles description: | 1P + N |
| Remote signalling: | With |
| Signal contacts composition: | 1 SD (1 C/O) |
| Surge arrester type: | Electrical distribution network |
| Earthing system: | TN-STT |
| Surge arrester class type: | Type 1 + 2 |
|---|---|
| Surge arrester technology: | MOV + GDT |
| [Ue] rated operational voltage: | 230 V AC (+/- 10 %) at 50...60 Hz |
| Nominal discharge current: | 20 kA |
| Maximum discharge current: | 50 kA |
| [Iimp] impulse current: | Common mode: 50 kA N/PEDifferential mode: 12.5 kA L/N |
| [Uc] maximum continuous operating voltage: | Differential mode: 350 V L/NCommon mode: 255 V N/PE |
| Maximum [Up] voltage protection level: | |
| Residual current: | 0.003 mA N/PE |
| [Ut] temporary overvoltage: | 337 V L/N 5 s withstand1200 V N/PE 200 ms safe failure mode |
| Disconnector device type: | Associated fuse gG 160 A 120 kA standardAssociated circuit breaker Compact NSX160E 80 A 25 kA standard |
| Local signalling: | Operating: mechanical indicator (white)End of life: mechanical indicator (red) |
| Mounting mode: | Clip-on (DIN rail) |
| 9 mm pitches: | 4 |
| Height: | 89 mm |
| Width: | 36 mm |
| Depth: | 69 mm |
| Net weight: | 290 g |
| Colour: | White (RAL 9003) |
| Material: | PA6 |
| Connections - terminals: | Tunnel type terminal (phase) 10...25 mm² flexibleTunnel type terminal (phase) 10...35 mm² rigidTunnel type terminal (earth) 16...25 mm² flexibleTunnel type terminal (earth) 16...35 mm² rigid |
| Wire stripping length: | 14 mm |
| Tightening torque: | 3.5 N.m |
| Impulse current: | 12.5 kA |
| Compatibility code: | IPRD1 |
| Market segment: | ResidentialSmall commercial |
| IK degree of protection: | IK05 conforming to IEC 62262 |
|---|---|
| Pollution degree: | 3 |
| Relative humidity: | 5...95 % |
| Operating altitude: | 2000 m |
| Ambient air temperature for operation: | -25...60 °C |
| Ambient air temperature for storage: | -40...80 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606481490209 |
|---|
