Motor circuit breaker, TeSys GV3, 3P, 25 A, magnetic, rotary handle, EverLink terminals - GV3L25
SKU : GV3L25
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Motor circuit breaker, TeSys GV3, 3P, 25 A, magnetic, rotary handle, EverLink terminals - GV3L25
DESCRIPTION
| Range: | TeSysTeSys Deca |
|---|---|
| Range of product: | TeSys GV3TeSys Deca |
| Product name: | TeSys GV3TeSys Deca |
| Product or component type: | Circuit breaker |
| Device short name: | GV3L |
| Device application: | Motor |
| Poles description: | 3P |
| Network type: | AC |
| Utilisation category: | Category A conforming to IEC 60947-2AC-3 conforming to IEC 60947-4-1 |
| Network frequency: | 50/60 Hz |
| Breaking capacity: | 100 kA Icu at 230/240 V AC 50/60 Hz100 kA Icu at 400/415 V AC 50/60 Hz50 kA Icu at 440 V AC 50/60 Hz12 kA Icu at 500 V AC 50/60 Hz6 kA Icu at 690 V AC 50/60 Hz |
| [Ics] rated service short-circuit breaking capacity: | 100 % at 230/240 V AC 50/60 Hz100 % at 400/415 V AC 50/60 Hz100 % at 440 V AC 50/60 Hz50 % at 500 V AC 50/60 Hz50 % at 690 V AC 50/60 Hz |
| Trip unit technology: | Magnetic |
| Magnetic tripping current: | 350 A |
| Fixing mode: | 35 mm symmetrical DIN rail: clippedPanel: screwed (with 3 x M4 screws) |
|---|---|
| Operating position: | Any position |
| Motor power kW: | 11 kW at 400/415 V AC 50/60 Hz15 kW at 500 V AC 50/60 Hz18.5 kW at 690 V AC 50/60 Hz |
| Control type: | Rotary knob |
| [In] rated current: | 25 A |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ui] rated insulation voltage: | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage: | 6 kV conforming to IEC 60947-2 |
| Mechanical durability: | 50000 cycles |
| Electrical durability: | 50000 cycles for AC-3 at 415 V |
| Maximum operating rate: | 25 cyc/h |
| Direct connector: | Without |
| Connections - terminals: | EverLink BTR screw connectors 1 cable(s) 1...35 mm² solidEverLink BTR screw connectors 2 cable(s) 1...25 mm² solidEverLink BTR screw connectors 1 cable(s) 1...35 mm² flexible without cable endEverLink BTR screw connectors 2 cable(s) 1...25 mm² flexible without cable endEverLink BTR screw connectors 1 cable(s) 1...35 mm² flexible with cable endEverLink BTR screw connectors 2 cable(s) 1...25 mm² flexible with cable end |
| Tightening torque: | 5 N.m on EverLink BTR screw connectors for cable 25 mm²8 N.m on EverLink BTR screw connectors for cable 35 mm² |
| Mechanical robustness: | Shocks: 15 Gn for 11 ms closed conforming to IEC 60068-2-27Shocks: 30 Gn for 11 ms opened conforming to IEC 60068-2-27Vibrations: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| Suitability for isolation: | Yes conforming to IEC 60947-1 |
| Height: | 132 mm |
| Width: | 55 mm |
| Depth: | 136 mm |
| Product weight: | 0.96 kg |
| Compatibility code: | GV3L |
| Standards: | EN/IEC 60947-2EN/IEC 60947-4-1CSA C22.2 No 60947-4-1UL 60947-4-1 |
|---|---|
| Product certifications: | IECEE CB SchemeULCSACCCEACABSLROS (Lloyds register of shipping)DNV-GLBVUKCA |
| Protective treatment: | TH |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| IK degree of protection: | IK09 |
| Ambient air temperature for operation: | -20...60 °C |
| Ambient air temperature for storage: | -40...80 °C |
| Fire resistance: | 960 °C conforming to IEC 60695-2-1 |
| Operating altitude: | 0...3000 m |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389119405423 |
|---|
