PanelSet PLM - Wall-mounting encl. polyester monobloc IP66 H1056xW852xD350mm+bakelite m.plate - NSYPLM108BG
DESCRIPTION
| Range: | PanelSet PLM |
|---|---|
| Product name: | PanelSet PLM PLM |
| Device short name: | PLM |
| Device application: | Multi-purpose |
| Product or component type: | Compact enclosure |
| Enclosure nominal height: | 1056 mm |
| Enclosure nominal width: | 852 mm |
| Enclosure nominal depth: | 350 mm |
| Enclosure mounting: | Wall mounted |
| Device composition: | 1 body1 door1 lock1 mounting plate |
| Door type: | Plain |
| Lock type: | 4 points lock, handle with 5 mm double bar insert |
| Number of locks: | 1 |
|---|---|
| Mounting plate description: | Plain bakelite |
| Accessibility for operation: | Front |
| Removable parts: | Door by hingesMounting plate by fixing element |
| Material: | Polyester reinforced with fibreglass |
| Colour: | Grey (RAL 7035) |
| Standards: | NEMA classification 13NEMA classification 4XIEC 62208 |
| Product certifications: | UL |
| IP degree of protection: | IP66 conforming to IEC 60529 |
|---|---|
| IK degree of protection: | IK10 conforming to IEC 62262 |
| Fire resistance: | 960 °C conforming to IEC 62208 |
| Ambient air temperature for operation: | -40...80 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3606480776410 |
|---|
