photo-electric sensor - XUY - fork - pot +/- - 50X42mm - 12..24VDC - M8 - XUYFNEP40050
SKU : XUYFNEP40050
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
photo-electric sensor - XUY - fork - pot +/- - 50X42mm - 12..24VDC - M8 - XUYFNEP40050
DESCRIPTION
| Range of product: | Telemecanique Photoelectric sensors XU |
|---|---|
| Series name: | Application |
| Electronic sensor type: | Photo-electric sensor |
| Sensor name: | XUY |
| Sensor design: | Fork |
| Detection system: | Thru beam |
| Emission: | Infrared LED, modulated |
| Passage width: | 50 mm |
| Passage depth: | 42 mm |
| Material: | Metal/plastic |
| Supply circuit type: | DC |
| Wiring technique: | 4-wire |
| Discrete output type: | PNP and NPN |
| Discrete output function: | 1 NO or 1 NC programmable |
| Electrical connection: | 1 male connector M8, 4 pins |
| Product specific application: | Detection of reference marksDetection of double sheetDetection on vibrating railDetection on small conveyorDetection of labels |
| [Sn] nominal sensing distance: | 50 mm |
| Enclosure material: | Painted aluminium and polyamide/glass |
|---|---|
| Keypad type: | Green |
| Minimum object diameter for detection: | 0.2 mm |
| Type of output signal: | Discrete |
| Output type: | Solid state |
| Status LED: | Adjustment mode and keypad locking: 1 LED (red)Output state: 1 LED (yellow) |
| [Us] rated supply voltage: | 12...24 V DC with reverse polarity protection |
| Supply voltage limits: | 10...30 V DC |
| Switching capacity in mA: | 100 mA (overload and short-circuit protection) |
| Switching frequency: | 10 kHz |
| Maximum voltage drop: | |
| Current consumption: | 40 mA no-load |
| Load capacitance: | 330 nF |
| Time response: | -20...20 µs |
| Setting-up: | Sensitivity by numeric potentiometer |
| Product weight: | 0.19 kg |
| Product certifications: | CEcULus |
|---|---|
| Ambient air temperature for operation: | -20...60 °C |
| Ambient air temperature for storage: | -30...80 °C |
| Immunity to ambient light: | 10000 lux natural light5000 lux incandescent bulb |
| Vibration resistance: | 7 gn, amplitude = +/- 0.75 mm (f = 10...55 Hz) conforming to IEC 60068-2-6 |
| Shock resistance: | 30 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
| IP degree of protection: | IP65 conforming to IEC 60529 |
| REACh Regulation: | Free of Substances of Very High Concern above the thresholdEU RoHS Directive |
| Code EAN: | 3389119006231 |
|---|
