PratiKa industrial socket - 63 A - 2P + E - 200...250 V AC - IP67 - 81278
DESCRIPTION
| Range: | PratiKa |
|---|---|
| Product name: | PratiKa socket |
| Product or component type: | Socket |
| Device short name: | PratiKa socket |
| Plug, socket category: | Low voltage |
| Poles description: | 2P + E |
| Network type: | AC |
| Outlet standard: | Industrial |
| Mounting mode: | Panel-mounted |
|---|---|
| Plug, socket, control station shape: | Angled |
| [In] rated current: | 63 A |
| [Ue] rated operational voltage: | 200...250 V |
| Network frequency: | 50/60 Hz |
| Ground lug clockwise position: | 6 h |
| Plug, socket material: | Housing: self-extinguishing engineering polymer |
| Contacts material: | Pins: stainless steelSleeves: nickel plated brassSprings: stainless steel |
| Connections - terminals: | Captive screws, completely loosened |
| Cable cross section: | 6...25 mm² |
| Product weight: | 0.424 kg |
| Base dimension: | 100 x 107 mm |
| Height: | 107 mm |
| Width: | 108 mm |
| Depth: | 129 mm |
| Colour: | Grey (RAL 7035) |
| Voltage colour: | Blue |
| Market segment: | Small commercial |
| Compatibility code: | PratiKa socket |
| Standards: | EN 60309-2EN 60309-1 |
|---|---|
| IP degree of protection: | IP67 conforming to IEC 60529 |
| IK degree of protection: | IK08 conforming to EN 62262 |
| Fire resistance: | 850 °C conforming to IEC 60695-2-11 |
| Relative humidity: | 50 % at 40 °C70 % at 30 °C90 % at 20 °C |
| Ambient air temperature for operation: | 35 °C ( 86400 s ) |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3303430812784 |
|---|
