Regulated Power Supply, 100-240V AC, 24V 0.4 A, single phase, Modular - ABLM1A24004
DESCRIPTION
| Range of product: | Modicon Power Supply |
|---|---|
| Product or component type: | Power supply |
| Power supply type: | Regulated switch mode |
| Variant option: | Modular |
| Enclosure material: | Plastic |
| Input voltage: | 100...240 V AC single phase100...240 V AC 2 phases |
| Input voltage limits: | 90...264 V AC |
| Rated power in W: | 10 W |
| Output voltage: | 24 V DC |
| Power supply output current: | 0.42 A |
| Network frequency limits: | 50...60 Hz |
|---|---|
| Earthing system: | TNTTIT |
| Maximum leakage current: | 0.25 mA 240 V AC |
| Input protection type: | Integrated fuse (not interchangeable) 1 AExternal protection (recommended) 20 A Curve BExternal protection (recommended) 20 A Curve CExternal protection (recommended) 2 A Curve BExternal protection (recommended) 2 A Curve C |
| Inrush current: | 15 A at 115 V30 A at 230 V |
| Power factor: | 0.52 at 115 V AC0.40 at 230 V AC |
| Efficiency: | 80 % at 115 V AC80 % at 230 V AC |
| Power dissipation in W: | 2.5 W |
| Current consumption: | |
| Response time: | |
| Holding time: | > 10 ms 115 V AC> 60 ms 230 V AC |
| Load capacitance: | 3000 µF |
| Residual ripple: | |
| Service life: | 10 year(s) |
| Meantime between failure [MTBF]: | 5000000 h at 25 °C, full load1000000 h at 55 °C, 80 % load |
| Output protection type: | Against overload and short-circuits, protection technology: automatic resetAgainst over temperature, protection technology: manual or automatic resetAgainst overvoltage, protection technology: manual or automatic reset |
| Connections - terminals: | Screw connection: 0.5...1.5 mm², (AWG 20...AWG 16) without wire end ferrule for input/outputScrew connection: 0.5...1 mm², (AWG 20...AWG 18) with wire end ferrule for input/output |
| Line and load regulation: | |
| Status LED: | 1 LED (green)output voltage |
| Depth: | 55.6 mm |
| Height: | 91 mm |
| Width: | 18 mm |
| Product weight: | 0.099 kg |
| Output coupling: | Serial |
| Mounting support: | Top hat type TH35-15 rail conforming to IEC 60715Top hat type TH35-7.5 rail conforming to IEC 60715Double-profile DIN rail panel mounting |
| Supply: | SELV conforming to EN/IEC 60950-1SELV conforming to EN/IEC 60204-1SELV conforming to IEC 60364-4-41 |
| Standards: | EN 62368-1EN/IEC 61010-1EN 61010-2-201EN/IEC 61204-3EN 61000-6-1EN 61000-6-2EN 61000-6-3EN 61000-6-4EN 61000-3-2EN 61000-3-3UL 62368-1UL 61010-1UL 61010-2-201CSA C22.2 No 62368-1CSA C22.2 No 61010-1CSA C22.2 No 61010-2-201EN/IEC 62368-1 |
|---|---|
| Product certifications: | CECUL listedCUL recognizedRCMCB SchemeEACKCNEC: class 2 |
| Operating altitude: | 2000 m...5000 m overvoltage category II |
| Shock resistance: | 100 m/s² for 11 ms |
| IP degree of protection: | IP20 |
| Ambient air temperature for operation: | -25...55 °C (without current derating)55...70 °C (with current derating of 2.67 % per °C) |
| Ambient air temperature for storage: | -40...85 °C |
| Relative humidity: | 0...95 % without condensation |
| Overvoltage category: | II |
| Electrical energy source class conforming to IEC 62368-1: | ES1 |
| Electrical shock protection class: | Class II without PE connection |
| Pollution degree: | 2 |
| Vibration resistance: | 3 mm (f= 2...9 Hz) conforming to IEC 60721-3-310 m/s² (f= 9...200 Hz) conforming to IEC 60721-3-3 |
| Electromagnetic compatibility: | Immunity to electrostatic discharge - test level: 6 kV (contact discharge) conforming to EN/IEC 61000-4-2Immunity to electrostatic discharge - test level: 9 kV (air discharge) conforming to EN/IEC 61000-4-2Electromagnetic field immunity test - test level: 10 V/m (80 MHz...2 GHz) conforming to EN/IEC 61000-4-3Electromagnetic field immunity test - test level: 5 V/m (2...2.7 GHz) conforming to EN/IEC 61000-4-3Electromagnetic field immunity test - test level: 3 V/m (2.7...6 GHz) conforming to EN/IEC 61000-4-3Immunity to fast transients - test level: 4 kV (on input-output) conforming to EN/IEC 61000-4-4Surge immunity test - test level: 3 kV (between power supply and earth) conforming to EN/IEC 61000-4-5Surge immunity test - test level: 1.5 kV (between phases) conforming to EN/IEC 61000-4-5Immunity to conducted disturbances - test level: 10 Vrms (0.15...80 MHz) conforming to EN/IEC 61000-4-6Immunity to magnetic fields - test level: 30 A/m (50...60 Hz) conforming to EN/IEC 61000-4-8Immunity to voltage dips - test level: 100 % (1 cycle) conforming to EN/IEC 61000-4-11Immunity to voltage dips - test level: 60 % (10 cycles) conforming to EN/IEC 61000-4-11Immunity to voltage dips - test level: 30 % (25 cycles) conforming to EN/IEC 61000-4-11Disturbing field emission conforming to EN 55016-2-3Limits for harmonic current emissions conforming to EN 61000-3-2Conducted disturbance emission conforming to EN 55016-1-2Conducted disturbance emission conforming to EN 55016-2-1 |
| Electromagnetic emission: | Conducted emissions conforming to EN 61000-6-3Radiated emissions conforming to EN 61000-6-4 |
| Dielectric strength: | 3000 V AC input/output |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3606481500106 |
|---|
