Safety switch, Telemecanique Safety switches XCS, metal key operated XCSA, 2NC + NO slow break, ATEX/IECEx - XCSA702EX
SKU : XCSA702EX
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Safety switch, Telemecanique Safety switches XCS, metal key operated XCSA, 2NC + NO slow break, ATEX/IECEx - XCSA702EX
DESCRIPTION
| Range of product: | Telemecanique Safety switches XCS |
|---|---|
| Product or component type: | Safety switch |
| Device short name: | XCSA |
| Material: | Metal |
| Head type: | Key operated turret head |
| Cable entry number: | 1 tapped entry for M20 x 1.5 cable gland (included) 7...13 mm |
| Electrical connection: | Terminal |
| Clamping connection capacity: | 1 x 0.5...2 x 1.5 mm² with or without cable end |
| Number of poles: | 3 |
| Contacts type and composition: | 2 NC + 1 NO |
| Contact operation: | Slow-break, break before make |
| Positive opening: | With NC contact |
| Locking options description: | Without locking of actuator |
| Local signalling: | Without |
|---|---|
| Mechanical durability: | 1000000 cycles |
| Minimum actuation speed: | 0.01 m/s |
| Maximum actuation speed: | 0.5 m/s |
| Contact code designation: | A300, AC-15 (Ue = 120 V, Ie = 6 A) conforming to EN/IEC 60947-5-1A300, AC-15 (Ue = 240 V, Ie = 3 A) conforming to EN/IEC 60947-5-1Q300, DC-13 (Ue = 125 V, Ie = 0.55 A) conforming to EN/IEC 60947-5-1Q300, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to EN/IEC 60947-5-1 |
| [Ithe] conventional enclosed thermal current: | 10 A |
| [Ui] rated insulation voltage: | 300 V conforming to UL 508500 V conforming to EN/IEC 60947-1300 V conforming to CSA C22.2 No 14 |
| [Uimp] rated impulse withstand voltage: | 6 kV conforming to EN/IEC 60947-5-1 |
| Short-circuit protection: | 10 A cartridge fuse type gG (gl) |
| Minimum actuator force for extraction: | 20 N |
| Maximum operating rate: | 10 cyc/mn for maximum durability |
| Body material: | Zamak |
| Head material: | Zamak |
| CAD overall width: | 40 mm |
| CAD overall height: | 114 mm |
| CAD overall depth: | 44 mm |
| Product weight: | 0.44 kg |
| Compatibility code: | XCSA |
| Safety level: | Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1Can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1Can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508 |
|---|---|
| Safety reliability data: | B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Protective treatment: | TC |
| Ambient air temperature for operation: | -25...70 °C |
| Ambient air temperature for storage: | -40...70 °C |
| Vibration resistance: | 5 gn (f= 10...500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance: | 10 gn for 11 ms conforming to IEC 60068-2-27 |
| Electrical shock protection class: | Class I conforming to EN/IEC 60536 |
| IP degree of protection: | IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 |
| Marking: | II2 D-Ex tb IIIC T85°C Db IP67 |
| Dust zone: | Zone 21 - 22 |
| Product certifications: | IEC-Ex INE 17.0020XINERIS 04ATEX0014X |
| Standards: | EN/IEC 60079-31EN/IEC 60079-0 |
| Directives: | 2014/34/EU - ATEX directive |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389119035842 |
|---|
