service connection circuit breaker DDI - 1P+N - 32..63 A - 300 mA type S - 16878
DESCRIPTION
| Circuit breaker application: | Distribution |
|---|---|
| Range: | Multi 9 |
| Range of product: | DDI |
| Product or component type: | Circuit breaker |
| Device short name: | DDI |
| Device location in system: | Group incomer |
| Poles description: | 1P + N |
| [In] rated current: | 40 A50 A32 A63 A |
| Earth-leakage sensitivity: | 300 mA |
| Earth-leakage protection time delay: | Selective |
| Neutral position: | Left |
| Standards: | EN 60898NF C 63-120 |
| Product certifications: | NF |
| Network type: | AC |
| Network frequency: | 50/60 Hz |
|---|---|
| [Ue] rated operational voltage: | 400 V AC 50/60 Hz conforming to EN 60898400 V AC 50/60 Hz conforming to NF C 63-120 |
| Residual current tripping technology: | Voltage dependent |
| [Ics] rated service breaking capacity: | 10 kA at 240 V AC 50/60 Hz conforming to NF C 63-1204.5 kA at 240 V AC 50/60 Hz conforming to EN 60898 |
| Control type: | Toggle |
| Mounting support: | Mounting plate |
| Height: | 210 mm |
| Width: | 70 mm |
| Depth: | 70 mm |
| Product weight: | 0.7 kg |
| Mechanical durability: | 10000 cycles |
| Connections - terminals: | Orientational terminals, cable cross section: 35 mm² |
| Earth-leakage protection: | Integrated |
| Rated current: | 32...63 A |
| Compatibility code: | DDI |
| Tropicalisation: | 1 conforming to EN 608981 conforming to NF C 63-120 |
|---|---|
| Relative humidity: | 90 % at 40 °C |
| Operating altitude: | 2000 m |
| Ambient air temperature for operation: | -15...70 °C |
