Socket, mixed contact, 16 A, relay type RPM2, screw clamp terminals, 250 V AC - RPZF2
SKU : RPZF2
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Socket, mixed contact, 16 A, relay type RPM2, screw clamp terminals, 250 V AC - RPZF2
DESCRIPTION
| Range of product: | Harmony Electromechanical Relays |
|---|---|
| Product or component type: | Socket |
| Contact terminal arrangement: | Mixed |
| Product compatibility: | Plug-in relay RPM with 2 C/O contact |
| Shape of pin: | Flat |
| Device short name: | RPZ |
| Sale per indivisible quantity: | 10 |
| Contacts type and composition: | 2 C/O |
| [In] rated current: | 16 A |
| Connections - terminals: | Screw clamp terminals |
| [Ith] conventional free air thermal current: | 16 A |
|---|---|
| [Ue] rated operational voltage: | |
| Tightening torque: | |
| Fixing mode: | By screw (panel)Clip-on (35 mm symmetrical DIN rail) |
| Marking: | CE |
| Width: | 30 mm |
| Net weight: | 0.054 kg |
| Group of product: | RPM_2_C/O_SC_TER_MIX_FLAT |
| Compatibility code: | RPZ |
| [Uimp] rated impulse withstand voltage: | 4 kV |
| Overvoltage category: | III |
| Pollution degree: | 3 |
| Connections - terminals: | - screw clamp terminals, flexible cable with cable end 1 x 0.5...1 x 2.5 mm² / AWG 20...AWG 14 - screw clamp terminals, solid cable without cable end 1 x 0.5...1 x 1.5 mm² / AWG 20...AWG 16 - screw clamp terminals, flexible cable with cable end 2 x 0.5...2 x 2.5 mm² / AWG 20...AWG 14 - screw clamps terminals, solid cable without cable end 2 x 0.5...2 x 1.5 mm² / AWG 20...AWG 16 |
|---|---|
| Standards: | IEC 61984 |
| Product certifications: | ULCSA |
| Ambient air temperature for storage: | -40...85 °C |
| Ambient air temperature for operation: | -40...55 °C |
| IP degree of protection: | IP20 conforming to EN/IEC 60529 |
| Dielectric strength: | 2500 V |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3389119402293 |
|---|
