Solid state relay, 3.5 A, DC switching, input 15...30 V DC, output 1...24 V DC - SSL1D03BD
SKU : SSL1D03BD
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Solid state relay, 3.5 A, DC switching, input 15...30 V DC, output 1...24 V DC - SSL1D03BD
DESCRIPTION
| Range of product: | Harmony Solid State Relays |
|---|---|
| Product or component type: | Solid state relay up to 10 A |
| Device short name: | SSL |
| Network number of phases: | 1 phase |
| [Uc] control circuit voltage: | 15...30 V |
| Output switching mode: | DC switching |
| Mounting support: | Socket |
|---|---|
| [In] rated current: | 3.5 A |
| Output voltage: | 1...24 V DC |
| [Uc] control circuit voltage: | 15...30 V DC |
| Capacitance unbalance: | 1.5 pF input/output |
| Minimum switching voltage: | 15 V DC turn-on |
| Maximum switching voltage: | 10 V DC turn-off |
| Input current limits: | 7 mA |
| Input impedance: | 3500 Ohm |
| Solid state output type: | Mosfet outputDC switching |
| Load current: | 0.001...3.5 A |
| Absolute maximum voltage: | 30 V DC |
| Maximum operating frequency: | 500 Hz |
| Surge current: | 9 A for 10 ms |
| Maximum voltage drop: | |
| Maximum leakage current: | 0.001 mA off-state |
| Response time: | 0.35 ms (turn-on)0.08 ms (turn-off) |
| Overvoltage category: | III |
| Width: | 5 mm |
| Height: | 28 mm |
| Depth: | 15 mm |
| Net weight: | 0.0041 kg |
| Device presentation: | Complete product |
| Flame retardance: | V0 conforming to UL 94 |
|---|---|
| Dielectric strength: | 2500 V for input/output |
| Pollution degree: | 2 |
| Product certifications: | ULCSA |
| Marking: | CE |
| Ambient air temperature for operation: | -20...80 °C |
| Ambient air temperature for storage: | -20...85 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606480579653 |
|---|
