Spacial SF enclosure with mounting plate - assembled - 2200x1200x800 mm - NSYSF2212802DP
SKU : NSYSF2212802DP
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Spacial SF enclosure with mounting plate - assembled - 2200x1200x800 mm - NSYSF2212802DP
DESCRIPTION
| Range: | Spacial |
|---|---|
| Product name: | Spacial SF |
| Device application: | Multi-purpose |
| Product or component type: | Suitable enclosure |
| Enclosure nominal height: | 2200 mm |
| Enclosure nominal width: | 1200 mm |
| Enclosure nominal depth: | 800 mm |
| Enclosure mounting: | Floor-standing |
| Device composition: | 2 sliding rails4 mounting plate bracket1 structure1 rear panel1 roof1 mounting plate2 door1 locking system with handle1 blocking system: left door |
| Structure type: | Formed from a single sectionVertical uprights joined with top and bottom framesPerforated structure with a pitch of 25 mmPanels and doors built into the structure |
|---|---|
| Door type: | Plain front |
| Number of doors: | Front face: 2 door(s) |
| Door opening side: | Left (120 °)Right (120 °) |
| Lock type: | 4 points lock, handle with 5 mm double bar insert front right door |
| Mounting plate description: | Plain |
| Type of gland plate: | Without gland plate |
| Accessibility for operation: | FrontSides of enclosureRear |
| Removable parts: | Door by screws hingeMounting plate by screws mounting plate bracketRear panel by screwsRoof by screwsMounting plate bracket by screwsSliding rail by screws |
| Material: | Frame: galvanised steelUprights: galvanised steelDoor: sheet steelPanels: sheet steelHinge: zamakHandle: polyamide 6 with 30 % fibre glass |
| Surface finish: | Epoxy-polyester powder |
| Colour: | Enclosure: grey (RAL 7035)Handle: black (RAL 9005) |
| Net weight: | 245.428 kg |
| Standards: | IEC 62208 |
|---|---|
| NEMA degree of protection: | NEMA 3R/12 |
| IP degree of protection: | IP55 conforming to IEC 60529 |
| IK degree of protection: | IK10 conforming to IEC 62262 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606485117928 |
|---|---|
| Substitution_texte: | Delivery in France only |
