sub-base - soldered electromechanical relays ABE7 - 8 channels - relay 10 mm - ABE7R08S210
DESCRIPTION
| Range of product: | Modicon ABE7 |
|---|---|
| Product or component type: | Electromechanical output relay sub-base |
| [Us] rated supply voltage: | 24 V DC for PLC end |
| Number of channels: | 8 |
| Number of terminal per channel: | 2 |
| Terminal block type: | Removable |
|---|---|
| Polarity distribution: | Volt-free |
| Fixing mode: | By clips (35 mm symmetrical DIN rail)By screws (solid plate with fixing kit) |
| Width: | 125 mm |
| Maximum current per output common: | 10 A |
| Current per channel: | 5 A for preactuator end |
| Minimum switching current: | 10 mA at >= 5 V |
| Drop-out voltage: | 2.4 V at 20 °C (PLC end) |
| Switching frequency: | |
| Threshold tripping voltage: | 19.7 V at 40 °C |
| Drop-out current: | 1 mA at 20 °C |
| Maximum power dissipation per channel in W: | 0.36 W (PLC end) |
| Contacts type and composition: | 1 NO for preactuator end |
| Maximum switching voltage: | 250 V AC 50/60 Hz conforming to IEC 60947-5-130 V DC conforming to IEC 60947-5-1 |
| Electrical durability: | 500000 cycles, maximum switching current: 600 mA at 24 V DC-13 10 ms (preactuator end)500000 cycles, maximum switching current: 1500 mA at 230 V AC-12 (preactuator end)500000 cycles, maximum switching current: 1500 mA at 24 V DC-12 (preactuator end)500000 cycles, maximum switching current: 900 mA at 230 V AC-15 (preactuator end) |
| Electrical reliability: | 1e-008 |
| Operating time: | |
| Contact bounce time: | |
| Operating rate in Hz: | 10 Hz no load0.5 Hz at Ie |
| Mechanical durability: | 20000000 cycles |
| [Uimp] rated impulse withstand voltage: | 2.5 kV conforming to IEC 60947-1 |
| [Ui] rated insulation voltage: | 2000 V |
| Installation category: | II conforming to IEC 60664-1 |
| Tightening torque: | 0.6 N.m with flat Ø 3.5 mm screwdriver |
| Product weight: | 0.448 kg |
| Max immunity to microbreaks: | 5 ms |
|---|---|
| Dielectric strength: | 2000 V conforming to IEC 60947-1 |
| Product certifications: | ULDNVCSAGLBVLROS (Lloyds register of shipping)EAC |
| IP degree of protection: | IP2x conforming to IEC 60529 |
| Protective treatment: | TC |
| Resistance to incandescent wire: | 750 °C, extinction time |
| Shock resistance: | 15 gn for 11 ms conforming to IEC 60068-2-27 |
| Resistance to radiated fields: | 10 V/m (26000000...1000000000 Hz) conforming to IEC 61000-4-3 level 3 |
| Resistance to fast transients: | 2 kV level 3 conforming to IEC 61000-4-4 |
| Ambient air temperature for operation: | -5...60 °C conforming to IEC 61131-2 |
| Ambient air temperature for storage: | -40...80 °C conforming to IEC 61131-2 |
| Pollution degree: | 2 conforming to IEC 60664-1 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110545265 |
|---|
