Switch disconnector, ComPacT NS1000 NA, 4P, fixed, manually operated, 1000A - C100S4NAFM
SKU : C100S4NAFM
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Switch disconnector, ComPacT NS1000 NA, 4P, fixed, manually operated, 1000A - C100S4NAFM
DESCRIPTION
| Range of product: | ComPacT NS630b...1600 new generation |
|---|---|
| Range: | ComPacT |
| Product name: | ComPacT NS new generation |
| Product or component type: | Switch disconnector |
| Device application: | Distribution |
| Poles description: | 4P |
| Network type: | AC |
| Breaking capacity code: | NA |
| Suitability for isolation: | Yes conforming to IEC 60947-3 |
| Network frequency: | 50/60 Hz |
|---|---|
| Control type: | Manually operated |
| Mounting mode: | Fixed |
| Upside connection: | Front |
| Downside connection: | Front |
| [Ie] rated operational current: | AC-23A: 1000 A AC 50/60 Hz 220/240 VAC-23A: 1000 A AC 50/60 Hz 380/415 VAC-23A: 1000 A AC 50/60 Hz 440/480 VAC-23A: 1000 A AC 50/60 Hz 500/525 VAC-23A: 1000 A AC 50/60 Hz 660/690 V |
| [Ui] rated insulation voltage: | 800 V AC 50/60 Hz conforming to IEC 60947-3 |
| [Uimp] rated impulse withstand voltage: | 8 kV conforming to IEC 60947-3 |
| [Ith] conventional free air thermal current: | 1000 A at 60 °C |
| [Icw] rated short-time withstand current: | 25 kA during 0.5 s conforming to IEC 60947-34 kA during 20 s conforming to IEC 60947-3 |
| [Icm] rated short-circuit making capacity: | 52 kA 690 V AC at 50/60 Hz |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz conforming to IEC 60947-3 |
| Contact position indicator: | Yes |
| Visible break: | No |
| Mechanical durability: | 10000 cycles conforming to IEC 60947-3 |
| Electrical durability: | 2000 cycles 440 V AC 50/60 Hz conforming to IEC 60947-3 |
| Connection pitch: | 70 mm |
| Height: | 280 mm |
| Width: | 327 mm |
| Depth: | 147 mm |
| Net weight: | 18 kg |
| Compatibility code: | NS1000 |
| Standards: | IEC 60947-3 |
|---|---|
| Product certifications: | IECEE CB Scheme |
| IP degree of protection: | IP40 conforming to IEC 60529 |
| IK degree of protection: | IK07 conforming to EN 50102 |
| Pollution degree: | 3 conforming to IEC 60947-3 |
| Ambient air temperature for operation: | -25...70 °C |
| Ambient air temperature for storage: | -50...85 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3606482101005 |
|---|
