switch disconnector ComPacT NSX400NA, 3 poles, 400 A, AC22A, AC23A - C403400S
SKU : C403400S
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
switch disconnector ComPacT NSX400NA, 3 poles, 400 A, AC22A, AC23A - C403400S
DESCRIPTION
| Range: | ComPacT new generation |
|---|---|
| Range of product: | ComPacT NSX400...630 new generation |
| Product name: | ComPacT NSX new generation |
| Device short name: | NSX400NA |
| Product or component type: | Switch disconnector |
| Device application: | Distribution |
| Poles description: | 3P |
| [Ith] conventional free air thermal current: | 400 A at 50 °C |
| [Ie] rated operational current: | AC-22A: 400 A AC 50/60 Hz 220...690 VAC-23A: 400 A AC 50/60 Hz 220...690 V |
| [In] rated current: | 400 A |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz |
| Network type: | AC |
| Network frequency: | 50/60 Hz |
| Suitability for isolation: | Yes conforming to EN/IEC 60947-3 |
| Utilisation category: | AC-22AAC-23A |
| Breaking capacity code: | NA |
| Contact position indicator: | Yes |
| Visible break: | No |
| Mounting mode: | Fixed |
| [Icw] rated short-time withstand current: | 5 kA during 1 s5 kA during 3 s1.93 kA during 20 s |
| [Icm] rated short-circuit making capacity: | 330 kA with upstream protection circuit breaker7.1 kA switch-disconnector alone |
| Control type: | Toggle |
| [Ui] rated insulation voltage: | 800 V AC 50/60 Hz |
| [Uimp] rated impulse withstand voltage: | 8 kV |
| Mounting support: | Backplate |
|---|---|
| Upside connection: | Front |
| Downside connection: | Front |
| Connection pitch: | 45 mm |
| Mechanical durability: | 15000 cycles |
| Electrical durability: | AC-22A: 10000 cycles 440 V AC 50/60 Hz In/2AC-22A: 2500 cycles 690 V AC 50/60 Hz InAC-22A: 5000 cycles 440 V AC 50/60 Hz InAC-22A: 5000 cycles 690 V AC 50/60 Hz In/2AC-23A: 10000 cycles 440 V AC 50/60 Hz In/2AC-23A: 2500 cycles 690 V AC 50/60 Hz InAC-23A: 5000 cycles 440 V AC 50/60 Hz InAC-23A: 5000 cycles 690 V AC 50/60 Hz In/2 |
| Width: | 140 mm |
| Height: | 255 mm |
| Depth: | 110 mm |
| Net weight: | 5.2 kg |
| Standards: | EN/IEC 60947-1EN/IEC 60947-3 |
| Product certifications: | CEEACCCC |
| Compatibility code: | NSX400 |
| IP degree of protection: | IP40 conforming to IEC 60529 |
|---|---|
| IK degree of protection: | IK07 conforming to IEC 62262 |
| Electrical shock protection class: | Class II |
| Pollution degree: | 3 conforming to IEC 60664-1 |
| Ambient air temperature for operation: | -25...70 °C |
| Ambient air temperature for storage: | -50...85 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3606482002876 |
|---|
