Switch disconnector, ComPacT NSXm 160NA, 4 poles, thermal current Ith 160A, compression lugs and busbar connectors - C124160BS
SKU : C124160BS
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Switch disconnector, ComPacT NSXm 160NA, 4 poles, thermal current Ith 160A, compression lugs and busbar connectors - C124160BS
DESCRIPTION
| Range: | ComPacT new generation |
|---|---|
| Range of product: | ComPacT NSXm new generation |
| Product name: | ComPacT NSXm new generation |
| Device short name: | NSXm 160NA |
| Product or component type: | Switch disconnector |
| Device application: | Distribution |
| Poles description: | 4P |
| [Ith] conventional free air thermal current: | 160 A at 40 °C |
| [Ie] rated operational current: | AC-23: 100 A AC 50/60 HzAC-22: 160 A AC 50/60 Hz |
| [In] rated current: | 160 A |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz |
| Network type: | AC |
| Network frequency: | 50/60 Hz |
| Suitability for isolation: | Yes conforming to EN/IEC 60947-3 |
| Utilisation category: | AC-22AAC-23A |
| Breaking capacity code: | NA |
| Contact position indicator: | Yes |
| Visible break: | No |
| Mounting mode: | Fixed |
| [Icw] rated short-time withstand current: | 1500 A during 1 s1500 A during 3 s335 A during 20 s |
| [Icm] rated short-circuit making capacity: | 2.13 kA switch-disconnector alone150 kA with upstream protection circuit breaker |
| Control type: | Toggle |
| [Ui] rated insulation voltage: | 800 V |
| [Uimp] rated impulse withstand voltage: | 8 kV |
| Mounting support: | 35 mm symmetrical DIN railBackplate |
|---|---|
| Connection pitch: | 27 mm |
| Connections - terminals: | 1 crimp lug wire size 2.5...120 mm², rigid or stranded aluminium/copper 1 crimp lug wire size 2.5...95 mm², flexible aluminium/copper bars |
| Mechanical durability: | 20000 cycles |
| Electrical durability: | AC-22A: 20000 cycles 440 V AC 50/60 Hz Ie/2AC-23A: 20000 cycles 440 V AC 50/60 Hz Ie/2AC-22A: 10000 cycles 440 V AC 50/60 Hz IeAC-23A: 10000 cycles 440 V AC 50/60 Hz IeAC-22A: 10000 cycles 690 V AC 50/60 Hz Ie/2AC-23A: 6000 cycles 690 V AC 50/60 Hz Ie/2AC-22A: 5000 cycles 690 V AC 50/60 Hz IeAC-23A: 3000 cycles 690 V AC 50/60 Hz Ie |
| Width: | 108 mm |
| Height: | 137 mm |
| Depth: | 80 mm |
| Net weight: | 1.42 kg |
| Standards: | EN/IEC 60947-1EN/IEC 60947-3 |
| Product certifications: | CEEACCCC |
| IP degree of protection: | IP40 conforming to IEC 60529 |
|---|---|
| IK degree of protection: | IK07 conforming to IEC 62262 |
| Electrical shock protection class: | Class II |
| Pollution degree: | 3 conforming to IEC 60664-1 |
| Ambient air temperature for operation: | -25...70 °C |
| Ambient air temperature for storage: | -50...85 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3606481995155 |
|---|
