switch-disconnector NG125NA - 3 poles - 80 A - 18890
SKU : 18890
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
switch-disconnector NG125NA - 3 poles - 80 A - 18890
DESCRIPTION
| Range of product: | NG125 |
|---|---|
| Range: | Acti9 |
| Product name: | Acti9 NG125NA |
| Product or component type: | Switch disconnector |
| Device short name: | NG125NA |
| Device application: | DistributionMaking and breaking under load |
| Poles description: | 3P |
| Number of protected poles: | 3 |
| Utilisation category: | AC-22A conforming to IEC 60947-3AC-22B conforming to IEC 60947-3AC-23B conforming to IEC 60947-3 |
| Suitability for isolation: | Yes conforming to IEC 60947-3 |
| [Ie] rated operational current: | 80 A at 500 V AC 50/60 Hz |
|---|---|
| [Ue] rated operational voltage: | 500 V AC 50/60 Hz |
| [Icm] rated short-circuit making capacity: | 2 kA switch-disconnector alone |
| [Icw] rated short-time withstand current: | 1.5 kA during 50 ms conforming to IEC 60947-3 |
| [Ui] rated insulation voltage: | 690 V AC 50/60 Hz conforming to IEC 60947-3 |
| [Uimp] rated impulse withstand voltage: | 8 kV conforming to IEC 60947-3 |
| Contact position indicator: | Yes |
| Control type: | Manual tripping testToggle |
| Local signalling: | ON/OFF indicationTrip indicator |
| Mounting mode: | Fixed |
| Mounting support: | 35 mm symmetrical DIN rail |
| Connection pitch: | 27 mm between phases |
| 9 mm pitches: | 9 |
| Height: | 103 mm |
| Width: | 81 mm |
| Depth: | 81 mm |
| Net weight: | 0.72 kg |
| Colour: | Black |
| Mechanical durability: | 20000 cycles |
| Electrical durability: | Category A (except AC20, DC20): 1500 cycles AC 50/60 Hz conforming to IEC 60947-3Category B (except AC20, DC20): 300 cycles AC 50/60 Hz conforming to IEC 60947-3 |
| Provision for padlocking: | Padlockable |
| Locking options description: | Integrated padlocking |
| Connections - terminals: | Tunnel type terminals (top or bottom) 16...70 mm² rigidTunnel type terminals (top or bottom) 10...50 mm² flexible |
| Wire stripping length: | Power circuit: 20 mm for top or bottom connection |
| Tightening torque: | Power circuit: 6 N.m top or bottom |
| Compatibility code: | NG125 |
| Standards: | EN 60947-3IEC 60947-3 |
|---|---|
| Product certifications: | VDE |
| IP degree of protection: | IP20 conforming to IEC 60529IP40 conforming to IEC 60529 |
| IK degree of protection: | IK05 |
| Pollution degree: | 3 conforming to IEC 60947-3 |
| Tropicalisation: | 2 conforming to IEC 60068-1 |
| Ambient air temperature for operation: | -10...60 °C |
| Ambient air temperature for storage: | -40...70 °C |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Unit Type of Package 1: | PCENumber of Units in Package 1 |
| Code EAN: | 3303430188902 |
|---|
