Télémécanique - Limit switch body ZCMD - 1NC+1NO - silver - slow-break - ZCMD25
SKU : ZCMD25
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Télémécanique - Limit switch body ZCMD - 1NC+1NO - silver - slow-break - ZCMD25
DESCRIPTION
| Range of product: | Telemecanique Limit switches XC Standard |
|---|---|
| Series name: | Standard format |
| Product or component type: | Limit switch body |
| Device short name: | ZCMD |
| Design: | Miniature |
| Body type: | Plug-in body |
| Associated head: | ZCE66ZCE28ZCEG1ZCE02ZCE01ZCE27ZCE13ZCE11ZCE64ZCEH0ZCE62ZCE14ZCE06ZCE65ZCE05ZCE29ZCE67ZCEH2ZCE07ZCE08ZCEF0ZCE24ZCEF2ZCE10ZCE21ZCE63 |
| Body material: | Zamak |
| Number of poles: | 2 |
| Contacts type and composition: | 1 NC + 1 NO |
| Contact operation: | Slow-break, break before make |
| Product compatibility: | XCMD |
|---|---|
| Associated connection component: | ZCMC25E2ZCMC25L1ZCMC25E3ZCMC25L7ZCMC25L5ZCMC25E10ZCMC25E1ZCMC25L10ZCMC25E7ZCMC25L2ZCMC25E5ZCMC25T06ZCMC25L3 |
| Electrical connection: | Plug-in without pre-cabled connection |
| Contacts insulation form: | Zb |
| Contacts material: | Silver plated contacts |
| Positive opening: | With |
| Minimum actuation speed: | 6 m/min |
| Contact code designation: | B300, AC-15 (Ue = 240 V), Ie = 1.5 A conforming to EN/IEC 60947-5-1 appendix AR300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to EN/IEC 60947-5-1 appendix A |
| [Ui] rated insulation voltage: | 300 V (pollution degree 3) conforming to UL 508400 V (pollution degree 3) conforming to IEC 60947-5-1300 V (pollution degree 3) conforming to CSA C22.2 No 14 |
| Maximum resistance across terminals: | 25 mOhm conforming to IEC 60255-7 category 3 |
| [Uimp] rated impulse withstand voltage: | 4 kV conforming to IEC 606644 kV conforming to IEC 60947-1 |
| Short-circuit protection: | 6 A cartridge fuse, type gG |
| Electrical durability: | 5000000 cycles, DC-13 120 V, 3 W, operating rate 5000000 cycles, DC-13 24 V, 4 W, operating rate 5000000 cycles, DC-13 48 V, 3 W, operating rate |
| Width: | 30 mm |
| Height: | 50 mm |
| Depth: | 16 mm |
| Device presentation: | Basic element |
| Compatibility code: | ZCMD |
| Ambient air temperature for storage: | -40...70 °C |
|---|---|
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110299106 |
|---|
