Télémécanique - limit switch XCR - roller lever - 2 C/O - ATEX/IECEx - XCRT115EX
DESCRIPTION
| Range of product: | OsiSense ATEX D |
|---|---|
| Series name: | Special format |
| Product or component type: | Limit switch |
| Product specific application: | For conveyor belt shift monitoring |
| Device short name: | XCR |
| Body type: | Fixed |
| Head type: | Rotary head |
| Material: | Metal |
| Fixing mode: | By the body |
| Movement of operating head: | Rotary |
| Type of operator: | Spring return roller zinc plated steel with lever |
| Switch actuation: | By conveyor belt |
| Type of approach: | Lateral approach, 2 directions |
| Electrical connection: | Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm² |
| Cable entry number: | 1 tapped entry for Pg 13.5 cable gland (included) 9...12 mm |
| Number of poles: | 2 |
| Contacts type and composition: | 2 x 1 C/O |
| Contacts insulation form: | Za |
| Contact operation: | Snap action |
| Number of steps: | 2 |
| Contact block per direction [control circuit]: | 1 per direction |
| Positive opening: | With |
| Minimum torque for tripping: | 1 N.m |
| Maximum actuation speed: | 1.5 m/s |
| IP degree of protection: | IP65 conforming to IEC 60529 |
| Body material: | Zinc alloy |
|---|---|
| Minimum actuation speed: | 0.01 m/min |
| Tripping angle: | 10 ° for fault signalling18 ° for stopping of the conveyor belt |
| Maximum displacement angle: | -90 °90 ° |
| Contact code designation: | A300, AC-15 (Ue = 240 V), Ie = 3 A conforming to EN 60947-5-1A300, AC-15 (Ue = 240 V), Ie = 3 A conforming to IEC 60947-5-1 appendix AQ300, DC-13 (Ue = 250 V), Ie = 0.27 A conforming to EN 60947-5-1Q300, DC-13 (Ue = 250 V), Ie = 0.27 A conforming to IEC 60947-5-1 appendix A |
| [Ui] rated insulation voltage: | 300 V conforming to UL 508500 V conforming to NF C 20-040 group C500 V (pollution degree 3) conforming to IEC 60947-1500 V (pollution degree 3) conforming to VDE 0110 |
| Maximum resistance across terminals: | 25 MOhm conforming to IEC 60255-7 category 325 MOhm conforming to NF C 93-050 method A |
| [Uimp] rated impulse withstand voltage: | 6 kV conforming to IEC 606646 kV conforming to IEC 60947-1 |
| Short-circuit protection: | 10 A cartridge fuse, type gG |
| Electrical durability: | 5000000 cycles, DC-13, inductive load type, 120 V, 4 W, operating rate 5000000 cycles, DC-13, inductive load type, 24 V, 10 W, operating rate 5000000 cycles, DC-13, inductive load type, 48 V, 7 W, operating rate |
| Mechanical durability: | 300000 cycles |
| Marking: | II2 D-Ex tb IIIC T85°C Db IP66/67 |
| Width: | 85 mm |
| Height: | 95 mm |
| Depth: | 75 mm |
| Compatibility code: | XCR |
| Shock resistance: | 30 gn for 18 ms conforming to IEC 60068-2-27 |
|---|---|
| Vibration resistance: | 9 gn (f= 10...500 Hz) conforming to IEC 60068-2-6 |
| Electrical shock protection class: | Class I conforming to IEC 60536Class I conforming to NF C 20-030 |
| Ambient air temperature for operation: | -20...60 °C |
| Protective treatment: | TC |
| Dust zone: | Zone 21 - 22 |
| Product certifications: | INERIS 04ATEX0014XIEC-Ex INE 16.0048X |
| Standards: | EN/IEC 60079-31EN/IEC 60079-0 |
| Directives: | 2014/34/EU - ATEX directive |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389118027954 |
|---|
