Télémécanique - limit switch XCRT - metal enclosure zinc plated steel roller with lever - 2C/O - XCRT115
SKU : XCRT115
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Télémécanique - limit switch XCRT - metal enclosure zinc plated steel roller with lever - 2C/O - XCRT115
DESCRIPTION
| Range of product: | OsiSense XC |
|---|---|
| Series name: | Special format |
| Product or component type: | Limit switch |
| Product specific application: | For conveyor belt shift monitoring |
| Device short name: | XCRT |
| Sensor design: | - |
| Body type: | Fixed |
| Head type: | Rotary head |
| Material: | Metal |
| Fixing mode: | By the body |
| Movement of operating head: | Rotary |
| Type of operator: | Spring return roller zinc plated steel with lever |
| Type of approach: | Lateral approach, 2 directions |
| Electrical connection: | Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm² |
| Number of poles: | 2 |
| Contacts type and composition: | 2 C/O |
| Contact operation: | Snap action |
| Contact block per direction [control circuit]: | 2 per direction |
| Positive opening: | Without |
| Body material: | Zinc alloy |
|---|---|
| Switch actuation: | By conveyor belt |
| Cable entry: | 1 entry tapped for Pg 13.5 cable gland, cable outer diameter: 9...12 mm conforming to NF C 68-300 |
| Contacts insulation form: | Za |
| Number of steps: | 2 |
| Minimum torque for tripping: | 1 N.m |
| Minimum actuation speed: | 0.01 m/min |
| Tripping angle: | 10 ° for fault signalling18 ° for stopping of the conveyor belt |
| Maximum displacement angle: | -90 °90 ° |
| Contact code designation: | A300, AC-15 (Ue = 240 V), Ie = 3 A conforming to EN/IEC 60947-5-1 appendix AQ300, DC-13 (Ue = 250 V), Ie = 0.27 A conforming to EN/IEC 60947-5-1 appendix A |
| [Ui] rated insulation voltage: | 300 V conforming to UL 508500 V (pollution degree 3) conforming to IEC 60947-1500 V (pollution degree 3) conforming to VDE 0110300 V conforming to CSA C22.2 No 14 |
| Maximum resistance across terminals: | 25 MOhm conforming to IEC 60255-7 category 3 |
| [Uimp] rated impulse withstand voltage: | 6 kV conforming to IEC 606646 kV conforming to IEC 60947-1 |
| Short-circuit protection: | 10 A cartridge fuse, type gG |
| Electrical durability: | 5000000 cycles, DC-13, inductive load type, 120 V, 4 W, operating rate 5000000 cycles, DC-13, inductive load type, 24 V, 7 W, operating rate 5000000 cycles, DC-13, inductive load type, 48 V, 10 W, operating rate |
| Mechanical durability: | 300000 cycles |
| Width: | 85 mm |
| Height: | 95 mm |
| Depth: | 75 mm |
| Product weight: | 1.17 kg |
| Terminals description ISO n°1: | (11-12)NC(13-14)NO |
| Compatibility code: | XCRT |
| Shock resistance: | 30 gn for 18 ms conforming to IEC 60068-2-27 |
|---|---|
| Vibration resistance: | 9 gn (f= 10...500 Hz) conforming to IEC 60068-2-6 |
| IP degree of protection: | IP65 conforming to IEC 60529 |
| Overvoltage category: | Class I conforming to IEC 61140Class I conforming to NF C 20-030 |
| Ambient air temperature for operation: | -25...70 °C |
| Ambient air temperature for storage: | -40...70 °C |
| Protective treatment: | TC |
| Standards: | EN 60947-5-1NF C 79-130CSA C22.2 No 14IEC 60947-5-1IEC 60204-1EN 60204-1 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110652499 |
|---|
