TeSys GV2, TeSys D & TeSys U - terminal block - 3P - from the top - GV1G09
SKU : GV1G09
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
TeSys GV2, TeSys D & TeSys U - terminal block - 3P - from the top - GV1G09
DESCRIPTION
| Range of product: | TeSys GV2TeSys KTeSys UTeSys D |
|---|---|
| Range: | Linergy |
| Product name: | FT |
| Device short name: | GV1G |
| Product or component type: | Terminal block |
| Accessory / separate part category: | Connection accessory |
| Poles description: | 3P |
| Range compatibility: | TeSys GV2TeSys DTeSys KTeSys UTeSys LS1 |
| [Ie] rated operational current: | 63 A |
|---|---|
| Mounting location: | Top |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| [Ui] rated insulation voltage: | 690 V conforming to IEC 60947-1 |
| Connections - terminals: | Screw clamp terminals 1 solid AWG 4Screw clamp terminals 1 cable(s) 1.5...16 mm² flexible with cable endScrew clamp terminals 1 cable(s) 1.5...16 mm² flexible without cable endScrew clamp terminals 1 cable(s) 1.5...25 mm² solidScrew clamp terminals 2 cable(s) 1.5...4 mm² flexible with cable endScrew clamp terminals 2 cable(s) 1.5...6 mm² solidScrew clamp terminals 2 cable(s) 2.5...4 mm² flexible without cable endScrew clamp terminals 1 flexible AWG 4 |
| Tightening torque: | 1.7 N.m - on screw clamp terminals2.2 N.m - on connector |
| Product weight: | 0.04 kg |
| Compatibility code: | GV1G |
| Sustainable offer status: | Green Premium product |
|---|---|
| REACh Regulation: | Free of Substances of Very High Concern above the threshold |
| REACh free of SVHC: | Yes |
| EU RoHS Directive: | Compliant |
| Toxic heavy metal free: | Yes |
| Mercury free: | Yes |
| RoHS exemption information: | Yes |
| China RoHS Regulation: | X |
| Environmental Disclosure: | ENVPEP111252EN |
| Code EAN: | 3389110212570 |
|---|
