TeSys GV4 - thermal magnetic circuit breaker - 80A 3P - with Everlink - GV4PE80S
SKU : GV4PE80S
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
TeSys GV4 - thermal magnetic circuit breaker - 80A 3P - with Everlink - GV4PE80S
DESCRIPTION
| Range: | TeSys |
|---|---|
| Product name: | TeSys GV4 |
| Product or component type: | Circuit breaker |
| Device short name: | GV4PE |
| Device application: | Motor protection |
| Protection type: | Short-circuitPhase lossOverloadShort time short-circuit protectionPhase unbalanceGround fault protection |
| Utilisation category: | Category A |
| Suitability for isolation: | Yes conforming to IEC 60947-1 |
| Poles description: | 3P |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [In] rated current: | 80 A |
| Trip unit technology: | Thermal-magneticElectronic |
| Magnetic tripping current: | 1360 A |
| [Isd] short-time pick-up adjustment range: | 13 x Ir |
| Thermal protection adjustment range: | 40...80 A |
| Motor tripping class: | 1020 |
| Phase failure sensitivity: | Yes conforming to IEC 60947-4-1 |
| Breaking capacity: | Icu 120 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2Icu 100 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2Icu 70 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2Icu 30 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2Icu 18 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2 100 kA at 208Y/120 V AC 50/60 Hz conforming to UL 60947 100 kA at 240 V AC 50/60 Hz conforming to UL 60947 65 kA at 480Y/277 V AC 50/60 Hz conforming to UL 60947Icu 10 kA at 660...690 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 600Y/347 V AC 50/60 Hz conforming to UL 60947 |
| [Ics] rated service breaking capacity: | 120 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2100 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-270 kA at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA at 500 V AC 50/60 Hz conforming to IEC 60947-218 kA at 525 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 660...690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage: | 8 kV conforming to IEC 60947-2 |
| [Ui] rated insulation voltage: | 800 V conforming to IEC 60947-2 |
| Mechanical durability: | 40000 cycles |
| Electrical durability: | 14000 cycles for AC-3 at 440 V In/27000 cycles for AC-3 at 440 V In |
| Motor power kW: | 37 kW at 400...415 V AC 50/60 Hz45 kW at 500 V AC 50/60 Hz22 kW at 400...415 V AC 50/60 Hz30 kW at 500 V AC 50/60 Hz37 kW at 660...690 V AC 50/60 Hz45 kW at 660...690 V AC 50/60 Hz55 kW at 660...690 V AC 50/60 Hz30 kW at 400...415 V AC 50/60 Hz37 kW at 500 V AC 50/60 Hz |
|---|---|
| Control type: | Toggle |
| Rotary handle padlocking: | With a lock accessory |
| Number of slots: | 1 slot(s) for alarm switch for fault signalling contact, plug-in1 slot(s) for voltage release for electrical remote tripping, plug-in1 slot(s) for auxiliary switch for open/close contact, plug-in |
| Local signalling: | Flashing LED (green) for readyLED (red) for alarm (T° >95%)Green indicator for presence of auxiliary contacts |
| Standards: | UL 60947-4-1EN/IEC 60947-2CSA C22.2 No 60947-4-1EN/IEC 60947-4-1 |
| Product certifications: | IECULCSACCCEACATEXEU-RO MR |
| Quality labels: | CE |
| Mounting mode: | By clipsBy screws |
| Mounting support: | Plate75 mm symmetrical DIN rail35 mm symmetrical DIN rail |
| Connections - terminals: | Top 1 EverLink BTR screw connectors wire size 1.5...70 mm², solidTop 1 EverLink BTR screw connectors wire size 1.5...50 mm², flexibleBottom 1 EverLink BTR screw connectors wire size 2.5...95 mm², solidBottom 1 EverLink BTR screw connectors wire size 2.5...70 mm², flexible |
| Connection pitch: | 27 mm |
| Wire stripping length: | 20 mm |
| Tightening torque: | 9 N.m for 16...95 mm²5 N.m for 1.5...10 mm² |
| Width: | 81 mm |
| Height: | 155 mm |
| Depth: | 116 mm |
| Product weight: | 1.45 kg |
| Colour: | Grey (RAL 7016) |
| Ambient air temperature for storage: | -50...85 °C |
|---|---|
| Ambient air temperature for operation: | -25...70 °C |
| Operating altitude: | 0...2000 m without derating2000...5000 m with derating |
| IP degree of protection: | IP40 front face conforming to IEC 60529 |
| IK degree of protection: | IK07 conforming to IEC 62262 |
| Pollution degree: | 3 conforming to IEC 60947-1 |
| Tropicalisation: | 2 conforming to IEC 68-2 |
| Mechanical robustness: | Vibrations: +/- 1 mm 2...13.2 Hz conforming to IEC 60068-2-6Vibrations: 0.7 gn 13.2...100 Hz conforming to IEC 60068-2-6Shocks: 15 gn 11 ms conforming to IEC 60068-2-27 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3606481310613 |
|---|
