TeSys K contactor - 4P (2 NO + 2 NC) - AC-1 <= 440 V 20 A - 230 V AC coil - LC1K09008P7
SKU : LC1K09008P7
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
TeSys K contactor - 4P (2 NO + 2 NC) - AC-1 <= 440 V 20 A - 230 V AC coil - LC1K09008P7
DESCRIPTION
| Range of product: | TeSys K |
|---|---|
| Range: | TeSys |
| Product or component type: | Contactor |
| Product name: | TeSys K |
| Device short name: | LC1K |
| Device application: | Control |
| Contactor application: | Resistive load |
| Utilisation category: | AC-1 |
|---|---|
| Poles description: | 4P |
| Pole contact composition: | 2 NO + 2 NC |
| [Ue] rated operational voltage: | Power circuit: 690 V AC 50/60 Hz |
| Control circuit type: | AC at 50/60 Hz |
| [Uc] control circuit voltage: | 230 V AC 50/60 Hz |
| [Uimp] rated impulse withstand voltage: | 8 kV |
| Overvoltage category: | III |
| [Ith] conventional free air thermal current: | 20 A (at 50 °C) for power circuit |
| Irms rated making capacity: | 110 A AC for power circuit conforming to NF C 63-110110 A AC for power circuit conforming to IEC 60947 |
| Rated breaking capacity: | 110 A at 415 V conforming to IEC 60947110 A at 440 V conforming to IEC 6094780 A at 500 V conforming to IEC 60947110 A at 220...230 V conforming to IEC 60947110 A at 380...400 V conforming to IEC 6094770 A at 660...690 V conforming to IEC 60947 |
| Associated fuse rating: | 25 A gG at 25 A aM for power circuit |
| Average impedance: | 3 mOhm - Ith 20 A 50 Hz for power circuit |
| [Ui] rated insulation voltage: | Power circuit: 600 V conforming to UL 508Power circuit: 690 V conforming to IEC 60947-4-1Power circuit: 600 V conforming to CSA C22.2 No 14 |
| Inrush power in VA: | 30 VA (at 20 °C) |
| Hold-in power consumption in VA: | 4.5 VA (at 20 °C) |
| Heat dissipation: | 1.3 W |
| Control circuit voltage limits: | Operational: 0.8...1.15 Uc (at Drop-out: 0.2...0.75 Uc (at |
| Connections - terminals: | Screw clamp terminals 1 cable(s) 1.5...4 mm²solidScrew clamp terminals 1 cable(s) 0.75...4 mm²flexible without cable endScrew clamp terminals 1 cable(s) 0.34...2.5 mm²flexible with cable endScrew clamp terminals 2 cable(s) 1.5...4 mm²solidScrew clamp terminals 2 cable(s) 0.75...4 mm²flexible without cable endScrew clamp terminals 2 cable(s) 0.34...1.5 mm²flexible with cable end |
| Maximum operating rate: | 3600 cyc/h |
| Signalling circuit frequency: | |
| Mounting support: | RailPlate |
| Tightening torque: | 1.3 N.m - on screw clamp terminals - with screwdriver Philips No 21.3 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm |
| Operating time: | 10...20 ms coil de-energisation and NO opening10...20 ms coil energisation and NO closing15...25 ms coil de-energisation and NC closing5...15 ms coil energisation and NC opening |
| Safety reliability level: | B10d = 1369863 cycles contactor with nominal load conforming to EN/ISO 13849-1B10d = 20000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1 |
| Mechanical durability: | 10 Mcycles |
| Electrical durability: | 0.18 Mcycles 20 A AC-1 at Ue |
| Mechanical robustness: | Shocks contactor closed, on X axis: 10 Gn for 11 ms conforming to IEC 60068-2-27Shocks contactor closed, on Y axis: 15 Gn for 11 ms conforming to IEC 60068-2-27Shocks contactor closed, on Z axis: 15 Gn for 11 ms conforming to IEC 60068-2-27Shocks contactor opened, on X axis: 6 Gn for 11 ms conforming to IEC 60068-2-27Shocks contactor opened, on Y axis: 10 Gn for 11 ms conforming to IEC 60068-2-27Shocks contactor opened, on Z axis: 10 Gn for 11 ms conforming to IEC 60068-2-27Vibrations contactor closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6Vibrations contactor opened: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| Height: | 58 mm |
| Width: | 45 mm |
| Depth: | 57 mm |
| Product weight: | 0.18 kg |
| Compatibility code: | LC1K |
| Standards: | BS 5424IEC 60947NF C 63-110VDE 0660 |
|---|---|
| Product certifications: | CSAUL |
| IP degree of protection: | IP2x conforming to VDE 0106 |
| Protective treatment: | TC conforming to IEC 60068TC conforming to DIN 50016 |
| Ambient air temperature for storage: | -50...80 °C |
| Operating altitude: | 2000 m without derating |
| Flame retardance: | V1 conforming to UL 94Requirement 2 conforming to NF F 16-101Requirement 2 conforming to NF F 16-102 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110489460 |
|---|
