TeSys K - differential thermal overload relays - 0.8...1.2 A - class 10A - LR2K0306
SKU : LR2K0306
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
TeSys K - differential thermal overload relays - 0.8...1.2 A - class 10A - LR2K0306
DESCRIPTION
| Range of product: | TeSys K thermal overload relays |
|---|---|
| Range: | TeSys |
| Product name: | TeSys LRK |
| Product or component type: | Differential thermal overload relay |
| Device short name: | LR2K |
| Relay application: | Motor protection |
| Product compatibility: | LC1KLC7KLP4KLP1K |
| Network type: | ACDC |
| Thermal overload class: | Class 10A conforming to IEC 60947-4-1 |
| Thermal protection adjustment range: | 0.8...1.2 A |
| [Ui] rated insulation voltage: | Power circuit: 690 V conforming to BS 4941Power circuit: 690 V conforming to IEC 60947Power circuit: 750 V conforming to VDE 0110 group CPower circuit: 600 V conforming to CSA C22.2 No 14 |
| Network frequency: | |
|---|---|
| Mounting support: | Under contactorPlate, with specific accessoriesRail, with specific accessories |
| Auxiliary contact composition: | 1 NO + 1 NC |
| [Ith] conventional free air thermal current: | 6 A for signalling circuit |
| [Ue] rated operational voltage: | 690 V AC AC-15 for signalling circuit250 V DC DC-13 for signalling circuit |
| Associated fuse rating: | 6 A gG for signalling circuit conforming to VDE 06606 A gG for signalling circuit conforming to IEC 60947 |
| [Uimp] rated impulse withstand voltage: | 6 kV |
| Power dissipation per pole: | 2 W |
| Phase failure sensitivity: | Yes conforming to IEC 60947-4-1 |
| Local signalling: | Trip indicator (yellow) |
| Control type: | Red push-button: trip test functionBlue push-button: stop and manual reset selector switch: manual or automatic reset |
| Connections - terminals: | Screw clamp terminals 1 cable(s) 1.5...4 mm²solidScrew clamp terminals 2 cable(s) 1.5...4 mm²solidScrew clamp terminals 1 cable(s) 0.75...4 mm²flexible without cable endScrew clamp terminals 2 cable(s) 0.75...4 mm²flexible without cable endScrew clamp terminals 1 cable(s) 0.34...2.5 mm²flexible with cable endScrew clamp terminals 2 cable(s) 0.34...1.5 mm²flexible with cable end |
| Tightening torque: | 1.3 N.m - on screw clamp terminals - with screwdriver Philips No 21.3 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm |
| Height: | 58 mm |
| Width: | 45 mm |
| Depth: | 65 mm |
| Product weight: | 0.145 kg |
| Compatibility code: | LR2K |
| Standards: | NF C 63-650IEC 60947BS 4941VDE 0660 |
|---|---|
| Product certifications: | CSAUL |
| Protective treatment: | TC conforming to IEC 60068TC conforming to DIN 50016 |
| IP degree of protection: | IP2x conforming to IEC 60529 |
| Ambient air temperature for operation: | -20...55 °C without derating conforming to IEC 60947-30...60 °C with derating conforming to IEC 60947 |
| Ambient air temperature for storage: | -40...70 °C |
| Operating altitude: | 2000 m without derating |
| Fire resistance: | 850 °C conforming to IEC 60695-2-1 |
| Flame retardance: | V1 conforming to UL 94Requirement 2 conforming to NF F 16-101Requirement 2 conforming to NF F 16-102 |
| Mechanical robustness: | Shocks NO contact: 10 Gn for 11 ms conforming to IEC 60068-2-27Shocks NC contact: 10 Gn for 11 ms conforming to IEC 60068-2-27Vibrations NO contact: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6Vibrations NC contact: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110230420 |
|---|
