TeSys Mini-VARIO - Switch body for switch-disconnector - 3 poles - 20 A - VN20
SKU : VN20
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
TeSys Mini-VARIO - Switch body for switch-disconnector - 3 poles - 20 A - VN20
DESCRIPTION
| Range: | TeSys |
|---|---|
| Product name: | TeSys Mini-VARIO |
| Device short name: | VN |
| Product or component type: | Switch body |
| Performance level: | Standard |
| Poles description: | 3P |
| Contacts type and composition: | 3 NO |
| Network type: | ACDC |
| Network frequency: | 50/60 Hz |
| Mounting support: | Symmetrical rail |
|---|---|
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz |
| [Uimp] rated impulse withstand voltage: | 6 kV |
| [Ith] conventional free air thermal current: | 20 A |
| [Ithe] conventional enclosed thermal current: | 16 A |
| [Ie] rated operational current: | 11 A (AC-23) at 400 V |
| Rated operational power in W: | 11 kW at 690 V (AC-23A)3 kW at 230...240 V (AC-3)4 kW at 400...415 V (AC-3)5.5 kW at 500 V (AC-3)5.5 kW at 690 V (AC-3)7.5 kW at 500 V (AC-23A)4 kW at 230...240 V (AC-23A)5.5 kW at 400...415 V (AC-23A) |
| Intermittent duty class: | 30 |
| Making capacity: | 200 A at 400 V AC-21A200 A at 400 V AC-22A200 A at 400 V AC-23A |
| [Icm] rated short-circuit making capacity: | 0.5 kA at 400 V at Ipeak |
| [Icw] rated short-time withstand current: | 140 A at 400 V duration: 1 s |
| Rated conditional short-circuit current: | 6 kA at 400 V - associated fuse 20 A aM6 kA at 400 V - associated fuse 20 A gG |
| Breaking capacity: | 200 A at 400 V (AC-21A)200 A at 400 V (AC-22A)200 A at 400 V (AC-23A) |
| Mechanical durability: | 50000 cycles |
| Electrical durability: | 30000 cycles DC-1...550000 cycles AC-21 |
| Suitability for isolation: | Yes |
| Connections - terminals: | Power circuit: screw clamp terminals4 mm² - solidPower circuit: screw clamp terminals4 mm² - flexible - with cable end |
| Tightening torque: | Power circuit: 0.7 N.m - on screw clamp terminals |
| Height: | 46.5 mm |
| Width: | 56 mm |
| Depth: | 62 mm |
| Product weight: | 0.11 kg |
| Compatibility code: | V |
| Standards: | IEC 60947-3 |
|---|---|
| Product certifications: | GLULCSAUKCA |
| Protective treatment: | TC |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| Mechanical robustness: | Shocks 11 ms (15 gn) conforming to IEC 60068-2-27Vibrations 10...150 Hz (1 gn) conforming to IEC 60068-2-6 |
| Ambient air temperature for operation: | -20...50 °C |
| Fire resistance: | 960 °C conforming to IEC 60695-2-1 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110759846 |
|---|
