TeSys VARIO - additional pole - 32 A - for V1 - VZ1
SKU : VZ1
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
TeSys VARIO - additional pole - 32 A - for V1 - VZ1
DESCRIPTION
| Range: | TeSys |
|---|---|
| Device short name: | VZ |
| Product or component type: | Additional pole |
| Performance level: | High performance |
| Poles description: | 1P |
| Contacts type and composition: | 1 NO |
| Product compatibility: | V1 |
| Range compatibility: | TeSys VARIO switch disconnector |
| Network type: | DCAC |
| Network frequency: | 50/60 Hz |
| Suitability for isolation: | Yes |
| Mounting location: | Left |
|---|---|
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz |
| [Uimp] rated impulse withstand voltage: | 8 kV |
| [Ith] conventional free air thermal current: | 32 A |
| [Ithe] conventional enclosed thermal current: | 25 A |
| Mechanical durability: | 100000 cycles |
| Electrical durability: | 100000 cycles AC-2130000 cycles DC-1...5 |
| Connections - terminals: | Power circuit: screw clamp terminals6 mm² - flexible - with cable endPower circuit: screw clamp terminals10 mm² - solid |
| Tightening torque: | Power circuit: 2.1 N.m - on screw clamp terminals |
| Height: | 74 mm |
| Width: | 16 mm |
| Depth: | 35 mm |
| Product weight: | 0.05 kg |
| Compatibility code: | Main pole module |
| Standards: | IEC 60947-3 |
|---|---|
| Product certifications: | CSAULGL |
| Protective treatment: | TC |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| Mechanical robustness: | Vibrations 10...150 Hz (1 gn) conforming to IEC 60068-2-6Shocks 11 ms (30 Gn) conforming to IEC 60068-2-27 |
| Ambient air temperature for operation: | -20...50 °C |
| Fire resistance: | 960 °C conforming to IEC 60695-2-1 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110551860 |
|---|
