Thermal magnetic circuit breaker, TeSys GB2, 1P+N, 0.5 A, Icu 50 kA@240 V - GB2CD05
SKU : GB2CD05
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
Thermal magnetic circuit breaker, TeSys GB2, 1P+N, 0.5 A, Icu 50 kA@240 V - GB2CD05
DESCRIPTION
| Range: | TeSys |
|---|---|
| Product name: | TeSys GB2 |
| Device short name: | GB2 |
| Product or component type: | Circuit breaker |
| Device application: | Control |
| Poles description: | 1P + N |
| Network type: | AC/DC |
| Utilisation category: | Category A conforming to IEC 60947-2DC-12 conforming to IEC 60947-5-1DC-13 conforming to IEC 60947-5-1 |
| Network frequency: | 50/60 Hz conforming to IEC 60947-2 |
| Breaking capacity: | 50 kA Icu at 110 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-21.5 kA Icu at 24 V DC conforming to IEC 60947-21 kA Icu at 48 V DC conforming to IEC 60947-2 |
| [Ics] rated service short-circuit breaking capacity: | 100 % at 110 V AC 50/60 Hz conforming to IEC 60947-225 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Trip unit technology: | Thermal-magnetic |
| Magnetic tripping current: | 6.6 A |
| Mounting mode: | By clips |
|---|---|
| Mounting support: | PlateRail |
| Mounting position: | HorizontalVertical |
| Control type: | Toggle |
| [In] rated current: | 0.5 A |
| [Ue] rated operational voltage: | 250 V AC 50/60 Hz conforming to IEC 60947-2277 V AC 60 Hz conforming to CSA C22.2 No 235277 V AC 60 Hz conforming to UL 107748 V DC |
| [Uimp] rated impulse withstand voltage: | 4 kV conforming to IEC 60947-2 |
| Power dissipation per pole: | 2 W |
| Mechanical durability: | 8000 cycles |
| Electrical durability: | 8000 cycles |
| Connections - terminals: | Connector 1 cable(s) 0.75...6 mm²solid without cable endConnector 2 cable(s) 0.75...4 mm²solid without cable endConnector 1 cable(s) 0.75...4 mm²flexible with cable endConnector 2 cable(s) 0.75...2.5 mm²flexible with cable end |
| Tightening torque: | 1.2 N.m on connector |
| Mechanical robustness: | Shocks: 22 Gn for 20 ms conforming to IEC 60068-2-27Vibrations: 5 Gn, 5...110 Hz conforming to IEC 60068-2-6 |
| Quantity per set: | Set of 6 |
| 9 mm pitches: | 2 |
| Height: | 74 mm |
| Width: | 15 mm |
| Depth: | 67 mm |
| Product weight: | 0.07 kg |
| Compatibility code: | GB2 |
| Standards: | EN/IEC 60947-1EN/IEC 60947-2CSA C22.2 No 235UL 1077 |
|---|---|
| Product certifications: | ULCSA |
| Protective treatment: | TC |
| IP degree of protection: | IP20 conforming to IEC 60529 |
| Ambient air temperature for operation: | -20...60 °C |
| Ambient air temperature for storage: | -40...80 °C |
| Fire resistance: | 960 °C conforming to IEC 60695-2-1 |
| Operating altitude: | 3000 m |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110214710 |
|---|
