trip unit MicroLogic 1.3 M for ComPacT NSX 400/630 circuit breakers, electronic, rating 320 A, 4 poles 3d - C4041M320
SKU : C4041M320
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
trip unit MicroLogic 1.3 M for ComPacT NSX 400/630 circuit breakers, electronic, rating 320 A, 4 poles 3d - C4041M320
DESCRIPTION
| Range: | ComPacT new generation |
|---|---|
| Range of product: | ComPacT NSX400...630 new generation |
| Product or component type: | Trip unit |
| Trip unit name: | Micrologic 1.3 M |
| Trip unit technology: | Electronic |
| Range compatibility: | ComPacT new generation NSX400ComPacT new generation NSX630 |
| Device application: | Motor |
| Poles description: | 4P |
| Protected poles description: | 3D |
| Neutral position: | Left |
| Trip unit protection functions: | SI |
| Protection type: | S |
| [In] rated current: | 320 A at 65 °C |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz |
| Network type: | AC |
| Network frequency: | 50/60 Hz |
| Mounting mode: | Fixed |
| Neutral protection setting: | No protection (3D) |
|---|---|
| Short-time pick-up adjustment type Isd: | Adjustable 9 settings |
| [Isd] short-time pick-up adjustment range: | 1600 A1920 A2240 A2560 A2880 A3200 A3520 A3840 A4160 A |
| Short-time delay adjustment type: | Fixed |
| Instantaneous pick-up adjustment type Ii: | Fixed |
| Instantaneous pick-up adjustment range: | 4800 A |
| Earth-leakage protection: | Without |
| Zone selective interlocking ZSI: | Without |
| Local signalling: | Flashing LED (green) for ready to operate |
| Standards: | EN/IEC 60947-2 |
|---|---|
| Electrical shock protection class: | Class II |
| Pollution degree: | 3 conforming to IEC 60947-1 |
| IP degree of protection: | IP40 conforming to IEC 60529 |
| Ambient air temperature for operation: | -25...70 °C |
| Ambient air temperature for storage: | -50...85 °C |
| REACh Regulation: | Reference contains Substances of Very High Concern above the thresholdEU RoHS Directive |
| Code EAN: | 3606482003323 |
|---|
