VIGILOHM IM10-H 110-230VCA - IMD-IM10-H
DESCRIPTION
| Range: | Vigilohm |
|---|---|
| Range of product: | Vigilohm |
| Product name: | Vigilohm IM |
| Device short name: | IM10-H |
| Product or component type: | Insulation monitoring device |
| Device application: | Hospital |
| Earthing system: | IT |
| User language: | ItalianSpanishChineseRussianEnglishPortugueseGermanFrench |
| Network rated voltage: | 0...230 V - AC at 50/60 Hz (phase to neutral) 0...100 V - DC |
|---|---|
| Insulation shield: | No |
| Type of measurement: | Network insulation resistance - measurement range: 1 kOhm...10 MOhm |
| Local signalling: | Green indicator light: satisfactory insulation resistanceOrange indicator light: below fault threshold |
| Threshold setting: | Fault: 50...500 kOhm |
| Response time: | |
| [Us] rated supply voltage: | 125...250 V DC +/- 15 %110...230 V AC 50/60 Hz +/- 15 % |
| Power consumption in VA: | 12 VA |
| Measurement voltage: | 25 V |
| Measurement current: | 0...0.2 mA |
| Relative impedance: | 110 kOhm - AC at 50/60 Hz |
| Test function: | Manual |
| Signal contacts composition: | 1 C/O standard or fail-safe |
| Signalling circuit voltage: | 250 V - AC at 6 A12...24 V - DC at 6 A |
| Communication port protocol: | - |
| Display type: | Digital display |
| Mounting mode: | Flush-mountedClip-on |
| Mounting support: | PanelDIN rail |
| Connections - terminals: | Removable screw terminal block0.2...2.5 mm² |
| Material: | Thermoplastic |
| Product weight: | 0.25 kg |
| Height: | 110 mm |
| Width: | 96 mm |
| Depth: | 59 mm |
| Market segment: | Small commercialResidential |
| Compatibility code: | IM10-H |
| Dielectric strength: | 4000 V - AC5500 V - DC |
|---|---|
| IP degree of protection: | Front face: IP52 |
| Environmental characteristic: | Exposure to damp heat not in service conforming to IEC 60068-2-30Exposure to damp heat in service conforming to IEC 60068-2-56Salt mist conforming to IEC 60068-2-52 |
| Pollution degree: | 2 |
| Type of installation: | Indoor |
| Standards: | IEC 61010-1IEC 61557-8IEC 60364-7-710IEC 61326-2-4 |
| Product certifications: | EACBVCEDNV |
| Ambient air temperature for operation: | -25...55 °C |
| Ambient air temperature for storage: | -40...70 °C |
| REACh Regulation: | Free of Substances of Very High Concern above the thresholdEU RoHS Directive |
| Code EAN: | 3606480321696 |
|---|
