voltage transformer - 230..400 V - 2 x 24 V - 320 VA - ABT7PDU032B
SKU : ABT7PDU032B
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
voltage transformer - 230..400 V - 2 x 24 V - 320 VA - ABT7PDU032B
DESCRIPTION
| Range of product: | Modicon Transformer Universal |
|---|---|
| Product or component type: | Safety and isolation transformer |
| Rated power in VA: | 320 VA |
| Input voltage: | 230 V AC single phase, terminal(s): N-L1400 V AC phase to phase, terminal(s): L1-L2 |
| Output voltage: | 24/48 V AC |
| Secondary winding: | Double |
| Protective cover: | With |
| Ambient air temperature for operation: | -20...60 °C |
| Input voltage limits: | 360...440 V207...253 V |
|---|---|
| Network frequency limits: | 47...63 Hz |
| Input voltage tolerance: | +/- 15 V |
| Efficiency: | 91 % |
| Power dissipation in W: | 31.6 W |
| Voltage variation at nominal load: | 0,0312 at 230 V0,0358 at 400 V |
| Output sustained overvoltage: | 0,023 (no load, hot state) |
| Maximum voltage drop at rated load: | 2.79 % |
| No load losses: | 15.1 W |
| Short-circuit voltage: | 0,067 |
| Output protection type: | Against overload, protection technology: externalAgainst overvoltage, protection technology: externalAgainst short-circuits, protection technology: external |
| Connections - terminals: | For input connection: screw type terminals, connection capacity: 5 x 4 mm² AWG 11For input ground connection: screw type terminals, connection capacity: 1 x 4 mm² AWG 11For output connection: screw type terminals, connection capacity: 4 x 4 mm² AWG 11 |
| Marking: | CE |
| Fixing mode: | By 4 screws diameter: 6.5 mm on vertical panel, operating position: horizontalBy 4 screws diameter: 6.5 mm on vertical panel, operating position: verticalBy 4 screws diameter: 6.5 mm on horizontal panel with derating to 90 % |
| Output coupling: | ParallelSeries by internal jumperGrounding of secondary |
| Operating altitude: | 3000 m |
| Electrical insulation class: | Class B |
| Status LED: | 1 LED (orange)input voltage |
| Width: | 123.0 mm |
| Height: | 153.0 mm |
| Depth: | 160.0 mm |
| Product weight: | 7.18 kg |
| Compatibility code: | ABT7 |
| Product certifications: | EACURDNV-GL |
|---|---|
| Standards: | UL 506 |
| IP degree of protection: | IP20 |
| Environmental characteristic: | EMC conforming to EN 62041Safety conforming to EN 61558-1Safety conforming to EN 61558-2-6 |
| Ambient air temperature for storage: | -40...80 °C |
| Relative humidity: | 0...95 % during operation |
| Overvoltage category: | Class I conforming to VDE 0106-1 |
| Dielectric strength: | 3200 V between input and ground3200 V between output and ground5100 V between input and output |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389119401111 |
|---|---|
| Substitution_texte: | Product not available. Here is the equivalent reference that we offer: Transformateur de commande et sécurité à connexion à vis primaire 230V à 400V et secondaire 24V~ à 48V~ - 400VA - LEGRAND |
