white light block with body/fixing collar with integral LED 230...240V - ZB6EM1B
SKU : ZB6EM1B
Regular price €0,00
Contact us for price and lead time for this product. Our team will respond quickly.
We offer reliable worldwide shipping through trusted logistics partners.
Most products ship within 2–4 weeks of order confirmation, depending on stock and supplier availability.
Once your order is shipped, you’ll receive a tracking link to follow the delivery.
For urgent requirements, please contact us before ordering — we’ll do our best to arrange faster dispatch.
We take great care in packaging and ensure all goods are delivered safely and promptly.
Lead time: 2–3 weeks – Ships quickly after order confirmation
white light block with body/fixing collar with integral LED 230...240V - ZB6EM1B
DESCRIPTION
| Range of product: | Harmony XB6 |
|---|---|
| Product or component type: | Complete body for pilot lights |
| Device short name: | ZB6 |
| Sale per indivisible quantity: | 5 |
| Connections - terminals: | Faston connectors, connection size: 2.8 x 0.5 mm |
| Light source: | LED |
| Bulb base: | Integral LED |
| Light block supply: | Direct |
| Light source colour: | White |
| [Us] rated supply voltage: | 230...240 V AC |
| CAD overall height: | 14 mm |
|---|---|
| CAD overall depth: | 58 mm |
| Terminals description ISO n°1: | (X1-X2)PL |
| Product weight: | 0.003 kg |
| Operating position: | Any position |
| [Ui] rated insulation voltage: | 250 V (pollution degree 3) conforming to EN/IEC 60947-1 |
| [Uimp] rated impulse withstand voltage: | 4 kV conforming to EN 60947-1 |
| Signalling type: | Steady |
| Supply voltage limits: | 195...264 V AC |
| Surge withstand: | 1 kV in contact conforming to IEC 61000-4-52 kV in free air conforming to IEC 61000-4-5 |
| Compatibility code: | ZB6 |
| Protective treatment: | TC |
|---|---|
| Ambient air temperature for storage: | -40...70 °C |
| Ambient air temperature for operation: | -25...70 °C |
| Electrical shock protection class: | Class II conforming to IEC 61140 |
| Standards: | EN/IEC 60947-5-5EN/IEC 60947-1UL 508CSA C22.2 No 14JIS C 852EN/IEC 60947-5-1JIS C 4520 |
| Product certifications: | GOSTCSACCCUL |
| Vibration resistance: | +/- 3 mm (f= 2...500 Hz) conforming to IEC 60068-2-65 gn (f= 2...500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance: | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-2750 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Resistance to fast transients: | 2 kV conforming to IEC 61000-4-4 |
| Resistance to electromagnetic fields: | 10 V/m conforming to IEC 61000-4-3 |
| Resistance to electrostatic discharge: | 6 kV on contact (on metal parts) conforming to IEC 61000-2-68 kV in free air (in insulating parts) conforming to IEC 61000-2-6 |
| Electromagnetic emission: | Class B conforming to IEC 55011 |
| Sustainable offer status: | Green Premium productREACh Regulation |
| Code EAN: | 3389110274813 |
|---|
